YASKAWA Varispeed G7 Series User Manual

5 -94
Note Attach a Momentary Power Interruption Compensation Unit if compensation for power interruptions of up to 2.0 seconds is required for 200 V Class
Inverters with outputs of 0.4 to 7.5 kW.
* 1. The initial settings for C6-02 are as follows: 0: Low noise PWM, 1: 2.0 kHz, 2: 5.0 kHz, 3: 8.0 kHz, 4: 10.0 kHz, 5: 12.5 kHz, and 6: 15.0 kHz. If the
carrier frequency is set higher than the factory setting for Inverters with outputs of 5.5 kW or more, the Inverter rated current will need to be reduced.
* 2. This setting is for software versions PRG 1039 and earlier.
The carrier frequencies for the settings of C6-11 are as follows:
1: 2.0 kHz, 2: 4.0 kHz, 3: 6.0 kHz, 4: 8.0 kHz.
Con-
stant
Number
Name Unit Factory Setting
–Inverter Capacity
kW 18.5 22 30 37 45 55 75 90 110
E2-11 Motor Rated Capacity
E4-07
2nd Motor Rated
Capacity
o2-04 kVA selection – 9 A B C D E F 10 11
b8-03
Energy-saving filter time
constant
s 0.50 (Open-loop vector control) 2.00 (Open-loop vector control)
b8-04 Energy-saving coefficient – 57.87 51.79 46.27 38.16 35.78 31.35 23.10 20.65 18.12
C6-02Carrier frequency selection–644444411
C6-11
Carrier frequency selection
for open-loop vector 2 con-
trol
*2
–442222211
–
Carrier frequency selection
upper limit
–664444411
E2-01
(E4-01)
Motor rated current A 65.8 77.2 105.0 131.0 160.0 190.0 260.0 260.0 260.0
E2-02
(E4-02)
Motor rated slip Hz 1.67 1.70 1.80 1.33 1.60 1.43 1.39 1.39 1.39
E2-03
(E4-03)
Motor no-load current A 15.7 18.5 21.9 38.2 44.0 45.6 72.0 72.0 72.0
E2-05
(E4-05)
Motor line-to-line resis-
tance
Ω 0.101 0.079 0.064 0.039 0.030 0.022 0.023 0.023 0.023
E2-06
(E4-06)
Motor leak inductance % 20.1 19.5 20.8 18.8 20.2 20.5 20.0 20.0 20.0
E2-10
Motor iron loss for torque
compensation
W 505 538 699 823 852 960 1200 1200 1200
L2-02
Momentary power loss
ridethru time
s 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-03 Min. baseblock (BB) time s 1.0 1.1 1.1 1.2 1.2 1.3 1.5 1.7 1.7
L2-04 Voltage recovery time s 0.6 0.6 0.6 0.6 1.0 1.0 1.0 1.0 1.0
L8-02 Overheat pre-alarm level °C 90 90 95 100 100 110 100 110 110
L8-39 Reduced carrier frequency kHz 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
N1-03
Hunting-prevention time
constant
ms 10 10 10 10 10 10 10 100 100
N5-02 Motor acceleration time s 0.317 0.355 0.323 0.320 0.387 0.317 0.403 0.410 0.580
