User Constant Tables
5- 101
* 1. The carrier frequency is as follows depending on the C6-02 setting.
1: 2.0 kHz, 2: 5.0 kHz, 3: 8.0 kHz, 4: 10.0 kHz, 5: 12.5 kHz, 6: 15.0 kHz, F: User setting (initial value for 400 V, 90 kW and 110 kW: 3.0 kHz)
* 2. C6-04 (Carrier Frequency Lower Limit) can be set only in V/f control and V/f control with PG modes.
* 3. Applicable for G7-Series Inverters with software versions PRG 1042 and later.
Con-
stant
Num-
ber
Name Unit Factory Setting
– Inverter Capacity kW 75 90 110 132 160 185 220 300
o2-04 kVA Selection 1 30 31 32 33 34 35 36 37
C6-02
*1
Carrier
frequency
selection
V/f
Factory setting –2
FF11111
Maximum
setting
–21111111
V/f with
PG
Factory setting –2FF11111
Maximum
setting
–21111111
Open-
loop
vector
Factory setting –2FF11111
Maximum
setting
–21111111
Flux
vector
Factory setting –1
F
*3
F
*3
F
*3
F
*3
F
*3
F
*3
1
Maximum
setting
–21111111
C6-03
(C6-04)
*2
Carrier
frequency
upper limit
(carrier
frequency
lower limit)
V/f
Factory setting kHz 5.0 3.0 3.0 2.0 2.0 2.0 2.0 2.0
Setting range kHz
0.4 to
5.0
0.4 to
3.0
0.4 to
3.0
0.4 to
2.0
0.4 to
2.0
0.4 to
2.0
0.4 to
2.0
0.4 to
2.0
V/f with
PG
Factory setting kHz 5.0 3.0 3.0 2.0 2.0 2.0 2.0 2.0
Setting range kHz
0.4 to
5.0
0.4 to
3.0
0.4 to
3.0
0.4 to
2.0
0.4 to
2.0
0.4 to
2.0
0.4 to
2.0
0.4 to
2.0
Open-
loop
vector
Factory setting kHz 5.0 3.0 3.0 2.0 2.0 2.0 2.0 2.0
Setting range kHz
2.0 to
5.0
2.0 to
3.0
2.0 to
3.0
2.0 to
2.0
2.0 to
2.0
2.0 to
2.0
2.0 to
2.0
2.0 to
2.0
Flux
vector
Factory setting kHz 2.0
1.5
*3
1.5
*3
1.5
*3
1.5
*3
1.5
*3
1.5
*3
2.0
Setting range kHz
2.0 to
5.0
1.5 to
3.0
*3
1.5 to
3.0
*3
1.5 to
2.0
*3
1.5 to
2.0
*3
1.5 to
2.0
*3
1.5 to
2.0
*3
2.0 to
2.0
