YASKAWA Varispeed G7 Series User Manual

Removing/Attaching the Digital Operator and Front Cover
1- 15
Fig 1.13 Mounting the Digital Operator
IMPORTANT
1. Do not remove or attach the Digital Operator or mount or remove the front cover using methods other than
those described above, otherwise the Inverter may break or malfunction due to imperfect contact.
2. Never attach the front cover to the Inverter with the Digital Operator attached to the front cover. Imperfect
contact can result.
Always attach the front cover to the Inverter by itself first, and then attach the Digital Operator to the front
cover.
A
B
1
2
TOE-S616-60.1.book 15 ページ ２０１７年８月４日 金曜日 午後３時４１分
