Data Tables
The data tables are shown below. The types of data are as follows: Reference data, monitor data, and broadcast
data.
Reference Data
The reference data table is shown below. You can both read and write reference data.
INFO
Set the number of data specified using command messages as quantity of specified messages x 2. Handle
response messages in the same way.
Register No. Contents
0000H Not used
0001H
Frequency reference
Bit 0
Forward Run/Stop Command 1: Forward run 0: Stop
Bit 1
Reverse Run/Stop Command 1: Reverse run 0: Stop
Bit 2
External fault 1: Error (EFO)
Bit 3
Fault reset 1: Reset command
Bit 4
ComRef
Note When this bit is set to 1 as ComRef, the frequency reference source will be transferred to MEMOBUS.
However, the Communications Option Board has priority of the frequency reference source when the
Communications Option Board is connected.
Bit 5
ComCtrl
Note When this bit is set to 1 as ComCtrl, the run command source will be transferred to MEMOBUS. How-
ever, the Communications Option Board has priority of the run command source when the Communica-
tions Option Board is connected.
Bit 6 Multi-function input command 3
Bit 7 Multi-function input command 4
Bit 8 Multi-function input command 5
Bit 9 Multi-function input command 6
Bit A Multi-function input command 7
Bit B Multi-function input command 8
Bit C Multi-function input command 9
Bit D Multi-function input command 10
Bit E Multi-function input command 11
Bit F Multi-function input command 12
0002H Frequency reference (Set units using constant o1-03)
0003H Not used
0004H Not used
0005H Not used
0006H PID target value
0007H Analog output 1 setting (-11 V/-1540 to 11 V/1540)
0008H Analog output 2 setting (-11 V/-1540 to 11 V/1540)
0009H
Multi-function contact output setting
Bit 0
Contact output (Terminal M1-M2) 1: ON 0: OFF
Bit 1
PHC1(Contact P1-PC) 1: ON 0: OFF
Bit 2
PHC2(Contact P2-PC) 1: ON 0: OFF
Bit 3
PHC3(Contact P3-C3) 1: ON 0: OFF
Bit 4
PHC4(Contact P4-C4) 1: ON 0: OFF
Bit 5 Not used
Bit 6 Set error contact (terminal MA-MC) output using bit 7. 1: ON 0: OFF
Bit 7
Error contact (terminal MA-MC) 1: ON 0: OFF
Bits 8 to F Not used
000AH to 000EH Not used
