Ground Fault Interrupters, Molded-case Circuit Breakers, and Magnetic Contactors
2- 5
400 V Class
Note 1. DC reactors to improve the power factor are built in to 400 V Class models for 18.5 to 300 kW as a standard feature.
2. Use a ground fault interrupter with high-frequency countermeasures and a sensitivity amperage of 30 mA or higher for each Inverter.
Example: NV Series by Mitsubishi Electric Corporation (manufactured in or after 1988)
EG or SG Series by Fuji Electric Co., Ltd. (manufactured in or after 1984)
Motor
Capacity
(kW)
Varispeed
G7 Model
CIMR-
G7A

Ground Fault Interrupter Molded-case Circuit Breaker Magnetic Contactor
Without
Reactor
With Reactor Without
Reactor
With Reactor Without
Reactor
With Reactor
Model Rated
Current
(A)
Model Rated
Current
(A)
Model Rated
Current
(A)
Model Rated
Current
(A)
Model Rated
Current
(A)
Model Rated
Current
(A)
0.4 40P4 NV30 3 NV30 3 NF30 3 NF30 3 SC-03 7 SC-03 7
0.75 40P7 NV30 5 NV30 5 NF30 5 NF30 5 SC-03 7 SC-03 7
1.5 41P5 NV30 10 NV30 10 NF30 10 NF30 10 SC-05 9 SC-05 9
2.2 42P2 NV30 15 NV30 10 NF30 15 NF30 10
SC-4-0 13 SC-4-0 13
3.7 43P7 NV30 20 NV30 15 NF30 20 NF30 15
SC-4-1 17 SC-4-1 17
5.5 45P5 NV30 30 NV30 20 NF30 30 NF30 20
SC-N2 32 SC-N1 25
7.5 47P5
NV30 30 NV30 30 NF30 30 NF30 30 SC-N2S 48 SC-N2 32
11 4011
NV50 50 NV50 40 NF50 50 NF50 40 SC-N2S 48 SC-N2S 48
15 4015
NV100 60 NV50 50 NF100 60 NF50 50 SC-N3 65 SC-N2S 48
18.5 4018
–– NV100 60 –– NF100 60 –– SC-N3 65
22 4022
–– NV100 75 –– NF100 75 –– SC-N4 80
30 4030
–– NV100 100 –– NF100 100 –– SC-N4 80
37 4037
–– NV225 125 –– NF225 125 –– SC-N5 90
45 4045
–– NV225 150 –– NF225 150 –– SC-N6 110
55 4055
–– NV225 175 –– NF225 175 –– SC-N7 150
75 4075
–– NV225 225 –– NF225 225 –– SC-N8 180
90 4090
–– NV400 250 –– NF400 250 –– SC-N10 220
110 4110
–– NV400 300 –– NF400 300 –– SC-N11 300
132 4132
–– NV400 350 –– NF400 350 –– SC-N11 300
160 4160
–– NV400 400 –– NF400 400 –– SC-N12 400
185 4185
–– NV600 500 –– NF600 500 –– SC-N12 400
220 4220
–– NV600 600 –– NF600 600 –– SC-N14 600
300 4300
–– NV800 800 –– NF800 800 –– NC-N16 800
