Conformance to CE Markings
10- 19
10
400V
Class
40P4 FS5972-10-07 10 1.2 141 × 46 × 330
40P7 FS5972-10-07 10 1.2 141 × 46 × 330
41P5 FS5972-10-07 10 1.2 141 × 46 × 330
42P2 FS5972-18-07 18 1.3 141 × 46 × 330
43P7 FS5972-18-07 18 1.3 141 × 46 × 330
44P0 FS5972-18-07 18 1.3 141 × 46 × 330
45P5 FS5972-35-07 35 2.1 206 × 50 × 355
47P5 FS5972-35-07 35 2.1 206 × 50 × 355
4011 FS5972-60-07 60 4.0 236 × 65 × 408
4015 FS5972-60-07 60 4.0 236 × 65 × 408
4018 FS5972-70-52 70 3.4 80 × 185 × 329
4022 FS5972-70-52 70 3.4 80 × 185 × 329
4030 FS5972-130-35 130 4.7 90 × 180 × 370
4037 FS5972-130-35 130 4.7 90 × 180 × 370
4045 FS5972-130-35 130 4.7 90 × 180 × 370
4055 FS5972-170-40 170 6 120 × 170 × 451
4075 FS5972-170-40 170 6 120 × 170 × 451
4090 FS5972-250-37 250 11.7 130 × 240 × 610
4110 FS5972-250-37 250 11.7 130 × 240 × 610
4132 FS5972-410-99 410 10 260 × 115 × 386
4160
FS5972-410-99 410 10 260 × 115 × 386
4185 FS5972-600-99 600 11 260 × 135 × 386
4220 FS5972-800-99 800 31.5 300 × 160 × 716
4300 FS5972-800-99 800 31.5 300 × 160 × 716
Table 10.6 DC Reactors for Suppressing Harmonics
Voltage Class
Inverter Model
CIMR-G7A
DC Reactor
Model Number Manufacturer Ratings Code Number
200 V Class
20P4
UZDA-B YASKAWA 5.4 A 8 mH X010048
20P7
400 V Class
40P4
UZDA-B YASKAWA 3.2 A 28 mH X010052
40P7
Table 10.5 EMC Noise Filters (Continued)
Volt-
age
Class
Inverter Model
CIMR-G7A
Noise Filter (Made by Schaffner)
Model Number Rated Current (A) Weight (kg) Dimensions (mm)
TOE-S616-60.1.book 19 ページ ２０１７年８月４日 金曜日 午後３時４１分
