September 2004 <5> Preface Addition: Warranty Information
Chapter 1 Addition: Removing and Attaching the Protection Cover
Chapter 2 Revision: Inverter main circuit configuration diagrams for models CIMR-F7A2037 to 2110 and
CIMR-F7A4075 to 4300
Addition: L
ON
W
ORKS
Communications Boards SI-J and SI-W1 in Table 2.14 Option Board
Specifications
Chapter 4 Addition: Setting 3 for Constant T1-01
Chapter 5
Chapter 5 Addition: Constant N1-03
Chapter 6
Chapter 10
Chapter 6 Deletion: Speed Limit Bias Setting under Torque Control
Chapter 7 Addition: PG Direction and PG Open in Table 7.4 Errors During Autotuning
Chapter 8 Addition: Procedure for Adjusting Constants after Replacement of Control Board
Chapter 9 Addition: L
ONWORKS Communications Boards SI-J and SI-W1 in Table 9.5 Option Boards
January 2004 <4> Chapter 2 Addition: Note 12 to connection diagram.
Note after main circuit configuration diagrams for C1MR-G7A2030 to 2110.
Explanation of I/O circuit configuration diagram for PG-B2.
Chapter 5 Addition: Values for 400 V Class Inverters of 300 kW under Factory Settings that Change with the
Inverter Capacity.
Note 5 for carrier frequency C6-03 to C6-05.
Chapter 6 Revision: Multi-function contact input terminals S7, S8 for multi-step operation to S9, S7.
Addition: Output Terminal Function
Explanation of restrictions on maximum output frequency depending on carrier fre-
quency under Reducing Noise and Leakage Current.
Using Inverters for Elevating Machines
Chapter 7 Revision: Main circuit capacitor neutral point potential error causes and corrective action under
Fault Detection.
Addition: Operator errors in table under Fault Detection.
Reset during Run Command input error under Alarm Detection.
Chapter 9 Revision: Input noise filter model numbers under
Specifications of Options and Peripheral
Devices.
Addition: Notes 4 and 5 under Common Specifications.
Chapter 10 Revision: Precautions for Open-loop Vector 2 Control.
Addition: Applications with Repetitive Loads
July 2003 <3> Chapter 4 Revision: Stationary Autotuning (T1-01=1)
Addition: Precautions After Using Rotational and Stationary Autotuning
April 2003 <2> Back cover Revision: Address
March 2003 <1> − Addition: Constants for the Inverters with software version PRG 102
, description of replacing
cooling fan and circulation fan, etc.
May 2001 – − First edition
Date of
Publication
Rev.
No.
Section Revised Content
