Modes
3- 11
Setting User Constants
Here, the procedure is shown to change C1-01 (Acceleration Time 1) from 10 s to 20 s.
Table 3.4 Setting User Constants in Advanced Programming Mode
Step
No.
Digital Operator Display Description
1 Turn ON the power supply.
2 Press the MENU Key to enter drive mode.
3 Press the MENU Key to enter quick programming mode.
4 Press the MENU Key to enter advanced programming mode.
5 Press the DATA/ENTER Key to access the monitor display.
6
Press the Increment or Decrement Key to display the C1-01 (Acceleration
Time 1).
7
Press the DATA/ENTER Key to access the setting display. The setting of C1-
01 (10.00) is displayed.
8 Press the Shift/RESET Key to move the flashing digit to the right.
9 Press the Increment Key to change set value to 20.00 s.
10 Press the DATA/ENTER Key to confirm the value.
11
“Entry Accepted” is displayed for 1.0 s after the data setting has been con-
firmed with the DATA/ENTER Key.
12 The monitor display for C1-01 returns.
Frequency Ref
-DRIVE-
U1-02=60.00Hz
U1-03=10.05A
Rdy
U1- 01=60.00Hz
** Main Menu **
-DRIVE-
Operation
** Main Menu **
-QUICK-
Quick Setting
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1-00=1
Select Language
Accel Time 1
-ADV-
(0.0←→6000.0)
10.0Sec
C1-00= 10.0Sec
Accel Time 1
-ADV-
(0.0←→6000.0)
10.0Sec
C1-01= 0 010.0Sec
Accel Time 1
-ADV-
(0.0←→6000.0)
10.0Sec
C1-01= 0 010.0Sec
Accel Time 1
-ADV-
(0.0←→6000.0)
10.0Sec
C1-01= 00 10.0Sec
Accel Time 1
-ADV-
(0.0←→6000.0)
10.0Sec
C1-01= 00 20.0Sec
Entry Accepted
-ADV-
Accel Time 1
-ADV-
(0.0←→6000.0)
10.0Sec
C1- 01= 20.0Sec
