10. Specifications
223
10. Specifications
 Standard Specifications (200 V Class)
Voltage Class 200 V single-/3-phase
Model
CIMR-
V7
*1
C

3-
phase
20P1 20P2 20P4 20P7 21P5 22P2 23P7 25P5 27P5
Single-
phase
B0P1 B0P2 B0P4 B0P7 B1P5 B2P2 B3P7 - -
Max. Applicable
Motor Output kW
*1
0.1 0.25 0.55 1.1 1.5 2.2 3.7 5.5 7.5
Inverter
Capacity
(kVA)
0.3 0.6 1.1 1.9 3.0 4.2 6.7 9.5 13
Rated Out-
put Current
(A)
0.8 1.6 3 5 8 11 17.5 25 33
Max. Output
Voltage (V)
3-phase, 200 to 230 V (proportional to input voltage)
Single-phase, 200 to 240 V (proportional to input voltage)
Max. Output
Frequency
(Hz)
400 Hz (Programmable)
Rated Input
Voltage and
Frequency
3-phase, 200 to 230 V, 50/60 Hz
Single-phase, 200 to 240 V, 50/60 Hz
Allowable
Voltage Fluc-
tuation
−15 to +10%
Allowable
Frequency
Fluctuation
±5%
Output CharacteristicsPower Supply
