48
MNTR Multi-function Monitoring
Selecting the Monitor
This function switches the operation; operation
using the digital operator including frequency
setting with potentiometer, operation using the
input terminals, or operation through communications
Setting can be changed using the or key.
LOCAL/REMOTE Selection
(Local)
(Remote)
Return to
Constant No./data
Sets and changes data for a constant No.
(Refer to page 52.)
Press the key. When is ON, data
can be displayed by selecting the monitor number.
Example: Monitoring the Output Voltage Reference
Select U-04 by
pressing the
or key.
Output voltage reference
is displayed.
or
To Next Page
