YASKAWA Varispeed V7 - Page 36

4. Wiring
35
Note: The wire size is given for copper wire at 75°C (160°F).
CIMR-
V7∗A
47P5
R/L1, S/L2, T/L3,
-, +1, +2, B1, B2,
U/T1, V/T2, W/T3
M5 2.5 5.5 to
8
10 to 8 5.5 10 600 V
vinyl-
sheathed
wire or
equivalent
Model Terminal Symbols Screws Tighten-
ing
Tor que
N•m
(lb•in)
Wires
Applicable Size Recommended
Size
Type
mm
2
AWG
mm
2
AWG
