* Terminal MA can be used only from DeviceNet communications. There is
no corresponding external output terminal.
• Output (Inverter → Master) Instance 156 (9C Hex)
Byte 1,
bit 7
Te r min al
P2
Operates the Inverter’s multi-function
output terminal P2. This function is en-
abled only when Inverter constant n059
is set to 18.
0: Terminal P2 OFF
1: Terminal P2 ON
Bytes
2 and 3
Speed
Reference
Indicates the Inverter’s speed reference.
The units depend on the setting in
Inverter constant n035.
The units are not affected by the speed
scale (SS) setting.
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Fault-
ed
Warn-
ing
Ready At Ref-
erence
Reset Rev
Run-
ning
ZSP Run-
ning
1Termi-
nal P2
Te rm i-
nal P1
Term i-
nal
MA*
--- Termi-
nal S4
Te rm i-
nal S3
Term i-
nal S2
Term i-
nal S1
2 Speed Actual (Low Byte)
3 Speed Actual (High Byte)
4 ---
5 ---
6 Output Current Monitor (Low Byte)
7 Output Current Monitor (High Byte)
