Note: 1. The Product Code depends on the Inverter capacity. For example, the
Product Code for the CIMR-V7NA20P2 is 3001.
2. The characters contain the capacity portion of the Inverter’s
model number. For example, if the Inverter is a CIMR-V7NA21P5,
the characters will contain 21P5.
Message Router Object (Class 02 Hex)
The Message Router object has a function that separates the DeviceNet
communications information. Both explicit messages and I/O messages
are always assigned functions through this object. The Message Router
object itself performs only internal processes and it does not have data
that is exchanged externally.
• Supported Services
01 05 Status Indicates the
Inverter's commu-
nications status.
--- 0001 OK --- Word
06 Serial
Number
Indicates the seri-
al number of the
Inverter communi-
cations.
--- Depends
on prod-
uct.
OK --- Long
07 Product
Name
Indicates the mod-
el number.
• V7N A
(See note 2.)
--- Capacity
characters
(See note
2.)
OK --- String
08 State Indicates the
Inverter's status.
• 3: Inverter
ready.
• 4: Inverter
error occurred.
--- 03 OK --- Byte
Service
Code
(Hex)
Service Name Description
0E Get_Attribute_
Single
Returns the contents of the specified
attribute.
In-
stance
At-
tribute
Name Contents Setting
Range
Factory Set-
ting (Hex)
Read Write Size
