Yealink SIP-T48G User Manual

User Guide for the SIP-T48G IP Phone
20
3) Connect the optional USB flash drive
Note
4) Connect the power
You have two options for power connections. Your system administrator will advise you which
one to use.
 AC power (Optional)
 Power over Ethernet (PoE)
AC Power (Optional)
To connect the AC power:
1. Connect the DC plug on the power adapter to the DC5V port on the phone and connect the
other end of the power adapter into an electrical power outlet.
Note
The IP phone should be used with Yealink original power adapter (5V/2A) only. The use of the
third-party power adapter may cause the damage to the phone.
The USB flash drive should be purchased separately if required.
The USB port can also be used to connect the Bluetooth USB dongle BT40 or Wi-Fi USB dongle
WF40. The Bluetooth USB dongle BT40 and Wi-Fi USB dongle WF40 should be purchased
separately. For more information on how to use the BT40 and WF40, refer to Yealink Bluetooth
USB Dongle BT40 User Guide and Yealink Wi-Fi USB Dongle WF40 User Guide .

Yealink SIP-T48G Specifications

General

Expansion module support	Yes
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Volume control	-
Display diagonal	7 \
Display resolution	800 x 480 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
AC adapter input voltage	100 - 240 V
Number of handles included	1 pc(s)

Weight and Dimensions

Width	266 mm
Height	185 mm
