Yealink VCM34 Administrator's Guide

| Managing the Directory | 228
Parameter Description Configuration Method
LDAP Name Filter
Configure the name attribute for
LDAP searching.
Example: (|(cn=%)(sn=%))
Web user interface
LDAP Number Filter
Configure the number attribute
for LDAP searching.
Example: (|(telephoneNumber=
%)(mobile=%))
Web user interface
LDAP TLS Mode
Configure the connection mode
between the LDAP server and
the system.
• LDAP—Unencrypted
connection between LDAP
server and the system (port
389 is used by default).
• LDAP TLS Start- TLS/SSL
connection between LDAP
server and the system (port
389 is used by default).
• LDAPs- TLS/SSL connection
between LDAP server and
the system (port 636 is used
by default).
Default: LDAP
Web user interface
LDAP Server Address Configure the domain name
or the IP address of the LDAP
server.
Web user interface
Port
Configure the LDAP server port.
Default: 389.
Web user interface
LDAP User Name
Configure the user name used to
log into the LDAP server.
Note: the user name is
provided by the LDAP server
administrator. If the LDAP server
allows ‘anonymous’ to login,
you don’t need to provide the
user name to access the LDAP
server.
Web user interface

Yealink VCM34 Specifications

General

Product type	Microphone
Product color	Black, Grey
LED indicators	Yes
Package depth	196 mm
Package width	310 mm
Package height	80 mm
Package weight	4260 g
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	2
Power source type	PoE
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Quantity	1
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	171.5 mm
Width	169 mm
Height	37.5 mm
