| Getting Started | 33

Left Side of VCH51 Cable Hub

Port Name Description

1 PC port Connect to PC via Type-C cable for content sharing.

2 HDMI Connect to PC via HDMI cable for sharing contents.

Right Side of VCH51 Cable Hub

Port Name Description

1 PoE Connect to the VC Hub/Phone port on the VCS codec or to

the PoE.

CP960 Conference Phone

You can use CP960 conference phone as a microphone and a speaker when you are having a call on

VC200/VC200-E/VC500/VC800/VC880/PVT980/PVT950. You can also place calls, answer calls or view

directory and history on CP960.

Main Page

Default Chapter2
