| Getting Started | 40

Rear Panel of MSpeaker

Name Description

1 Power Input It is used to connect MSpeaker to the power adapter.

2 AUX In It is used to connect MSpeaker to VC800 Line Out Port

as an audio input.

Hardware of MSpeaker II

Front Panel of MSpeaker II

Rear Panel of MSpeaker II

Name Description

1 Power Input It is used to connect MSpeaker to the power adapter.

2 Line In It is used to connect MSpeaker II to the Line Out Port as

an audio input.

3 Audio It is used to connect MSpeaker to the VC Hub/Camera

Port as an audio input.
