3-10
IM 04P01B01-17E
32001 Computed data of CH0A (lower word)
32002 Computed data of CH0A (upper word)
32003 Computed data of CH0B (lower word)
32004 Computed data of CH0B (upper word)
32005 Computed data of CH0C (lower word)
32006 Computed data of CH0C (upper word)
32007 Computed data of CH0D (lower word)
32008 Computed data of CH0D (upper word)
32009 Computed data of CH0E (lower word)
32010 Computed data of CH0E (upper word)
32011 Computed data of CH0F (lower word)
32012 Computed data of CH0F (upper word)
32013 Computed data of CH0G (lower word)
32014 Computed data of CH0G (upper word)
32015 Computed data of CH0J (lower word)
32016 Computed data of CH0J (upper word)
32017 Computed data of CH0K (lower word)
32018 Computed data of CH0K (upper word)
32019 Computed data of CH0M (lower word)
32020 Computed data of CH0M (upper word)
32021 Computed data of CH0N (lower word)
32022 Computed data of CH0N (upper word)
32023 Computed data of CH0P (lower word)
32024 Computed data of CH0P (upper word)
32025 Computed data of CH1A (lower word)
32026 Computed data of CH1A (upper word)
32027 Computed data of CH1B (lower word)
32028 Computed data of CH1B (upper word)
32029 Computed data of CH1C (lower word)
32030 Computed data of CH1C (upper word)
32031 Computed data of CH1D (lower word)
32032 Computed data of CH1D (upper word)
32033 Computed data of CH1E (lower word)
32034 Computed data of CH1E (upper word)
32035 Computed data of CH1F (lower word)
32036 Computed data of CH1F (upper word)
32037 Computed data of CH1G (lower word)
32038 Computed data of CH1G (upper word)
32039 Computed data of CH1J (lower word)
32040 Computed data of CH1J (upper word)
32041 Computed data of CH1K (lower word)
32042 Computed data of CH1K (upper word)
32043 Computed data of CH1M (lower word)
32044 Computed data of CH1M (upper word)
32045 Computed data of CH1N (lower word)
32046 Computed data of CH1N (upper word)
32047 Computed data of CH1P (lower word)
32048 Computed data of CH1P (upper word)
Input Register Data
• Registers corresponding to models with the /M1 computation function option.
• The data is a 32-bit signed integer. Two registers are assigned for each data point.
• The value is the same as the computed data in binary output format (see page 5-14).
• The decimal point and unit information are not included.
Set them on the Modbus master.
• Valid channels vary depending on the device. An error response (code 2) occurs when an
invalid channel is read.
3.4
Modbus Slave Protocol Specifications
To Next Page
