4-9
IM 04P01B01-17E
4
Commands
Miscellaneous
Channel Number
• Pen model
Measurement channel: 01 to 04
Computation channel: 0A, 0B, 0C, 0D, 0E, 0F, 0G, 0J
• Dot model
Measurement channel:
µR10000: 01 to 06
µR20000: 01 to 24
Computation channel:
µR10000: 0A, 0B, 0C, 0D, 0E, 0F, 0G, 0J, 0K, 0M, 0N, 0P
µR20000: 0A, 0B, 0C, 0D, 0E, 0F, 0G, 0J, 0K, 0M, 0N, 0P,
1A, 1B, 1C, 1D, 1E, 1F, 1G, 1J, 1K, 1M, 1N, 1P
Relay Number (/A1, /A2, /A3, /A4, and /A5 Options)
• Models with the /A1 option: I01, I02
• Models with the /A2 option: I01 to I04
• Models with the /A3 option: I01 to I06
• Models with the /A4 option: I01 to I06, I11 to I16 (µR20000)
• Models with the /A5 option: I01 to I06, I11 to I16, I21 to I26, I31 to I36 (µR20000)
Communication Input Data
µR10000 Pen model: C01 to C08, dot model: C01 to C12
µR20000 Pen model: C01 to C08, dot model: C01 to C24
Computation Constant (/M1 option).
K01 to K30
Remote Control Input Terminal (/R1 Option)
D01 to D05
Chart Speed on the Pen Model
5 6 8 9 10 12 15 16 18 20
24 25 30 32 36 40 45 48 50 54
60 64 72 75 80 90 96 100 120 125
135 150 160 180 200 225 240 250 270 300
320 360 375 400 450 480 500 540 600 675
720 750 800 900 960 1000 1080 1200 1350 1440
1500 1600 1800 2000 2160 2250 2400 2700 2880 3000
3600 4000 4320 4500 4800 5400 6000 7200 8000 9000
10800 12000
mm/h
4.3 Parameter Values
