4-8
IM 04P01B01-17E
• Resistance Temperature Detector (RTD)
Range Type Parameter for Range of Leftmost and Rightmost Values of Span
the SR Command °C SR Command °F SR Command
Pt100 PT –200.0 to 600.0°C –2000 to 6000 –328.0 to 1112.0°F –3280 to 11120
JPt100 JPT –200.0 to 550.0°C –2000 to 5500 –328.0 to 1022.0°F –3280 to 10220
Difference between channels (DELTA)
Pt100 - –800.0 to 800.0°C –8000 to 8000 –1440.0 to 1440.0°F –14400 to 14400
JPt100 - –750.0 to 750.0°C –7500 to 7500 fu–1350.0 to 1350.0°F–13500 to 13500
• ON/OFF input (DI)
Range Type Parameter for Range of Leftmost and Range of Leftmost and
the SR Command Rightmost Values of Span Rightmost Values of Span
of the SR Command
Level LEVEL 0 to 1
†
0 to 1
Contact CONT 0 to 1
††
0 to 1
†
“0” when less than 2.4 V, “1” when greater than or equal to 2.4 V.
††
“0” when contact is OFF, “1” when contact is ON.
• Cu10, Cu25 RTD input (/N1 Option)
Range Type Parameter for the SR Command
Cu10(GE) CU1
Cu10(L&N) CU2
Cu10(WEED) CU3
Cu10(BAILEY) CU4
Cu10: α=0.00392 at 20°C CU5
Cu10: α=0.00393 at 20°C CU6
Cu25: α=0.00425 at 0°C CU25
• Expansion inputs (/N3 Option)
Range Type Parameter for the SR Command
Kp vs Au7Fe Kp
PLATINEL PLATI
PR40 - 20 PR
NiNiMo NiMo
W/WRe26 W/WRe
Type N(AWG14) N2
Pt50 PT3
Ni100(SAMA) Ni1
Ni100(DIN) Ni2
Ni120 Ni3
J263*B J263
Cu53 CU8
Cu100 CU9
Pt25 PT4
4.3 Parameter Values
