4-7
IM 04P01B01-17E
4
Commands
4.3 Parameter Values
This section explains frequently used parameters.
Input Range
The following tables show the input types (VOLT, TC, RTD, DI, and 1-5V), range types,
and the ranges for the leftmost and rightmost values of the span.
• DC Voltage (VOLT), Square Root (SQRT), Difference between Channels (DELTA)
Range Type Parameter for Range of Leftmost and Range of Leftmost and
the SR Command Rightmost Values of Span Rightmost Values of Span
of the SR Command
20 mV 20 mV –20.00 to 20.00 mV –2000 to 2000
60 mV 60 mV –60.00 to 60.00 mV –6000 to 6000
200 mV 200 mV –200.0 to 200.0 mV –2000 to 2000
2 V 2 V –2.000 to 2.000 V –2000 to 2000
6 V 6 V –6.000 to 6.000 V –6000 to 6000
20 V 20 V –20.00 to 20.00 V –2000 to 2000
50 V 50 V –50.00 to 50.00 V –5000 to 5000
• 1-5V
Range Type Parameter for Range of Leftmost and Range of Leftmost and
the SR Command Rightmost Values of Span Rightmost Values of Span
of the SR Command
1-5V 1-5V Leftmost value: 800 to 1200
0.8000 to 1.200 V
Rightmost value: 4800 to 5200
4.8000 to 5.200 V
• Thermocouple (TC)
Range Type Parameter for Range of Leftmost and Rightmost Values of Span
the SR Command °C SR Command °F SR Command
RR 0.0 to 1760.0°C0 to 17600 32 to 3200°F 32 to 3200
SS 0.0 to 1760.0°C0 to 17600 32 to 3200°F 32 to 3200
BB 0.0 to 1820.0°C0 to 18200 32 to 3308°F 32 to 3308
KK –200.0 to 1370.0°C –2000 to 13700 –328 to 2498°F –328 to 2498
EE –200.0 to 800.0°C –2000 to 8000 –328.0 to 1472.0°F –3280 to 14720
JJ –200.0 to 1100.0°C –2000 to 11000 –328.0 to 2012.0°F –3280 to 20120
TT –200.0 to 400.0°C –2000 to 4000 –328.0 to 752.0°F –3280 to 7520
NN 0.0 to 1300.0°C0 to 13000 32 to 2372°F 32 to 2372
WW 0.0 to 2315.0°C0 to 23150 32 to 4199°F 32 to 4199
LL –200.0 to 900.0°C –2000 to 9000 –328.0 to 1652.0°F –3280 to 16520
UU –200.0 to 400.0°C –2000 to 4000 –328.0 to 752.0°F –3280 to 7520
WRe WRe 0.0 to 2400.0°C0 to 24000 32 to 4352°F 32 to 4352
Difference between channels (DELTA)
R- –1760.0 to 1760.0°C –17600 to 17600 –3168 to 3168°F –3168 to 3168
S- –1760.0 to 1760.0°C –17600 to 17600 –3168 to 3168°F –3168 to 3168
B- –1820.0 to 1820.0°C –18200 to 18200 –3276 to 3276°F –3276 to 3276
K- –1570.0 to 1570.0°C –15700 to 15700 –2826 to 2826°F –2826 to 2826
E- –1000.0 to 1000.0°C –10000 to 10000 –1800.0 to 1800.0°F –18000 to 18000
J- –1300.0 to 1300.0°C –13000 to 13000 –1999.9 to 2340.0°F –19999 to 23400
T- –600.0 to 600.0°C –6000 to 6000 –1080.0 to 1080.0°F –10800 to 10800
N- –1300.0 to 1300.0°C –13000 to 13000 –2340 to 2340°F –2340 to 2340
W- –1999.9 to 2315.0°C –19999 to 23150 –4167 to 4167°F –4167 to 4167
L- –1100.0 to 1100.0°C –11000 to 11000 –1980.0 to 1980.0°F –19800 to 19800
U- –600.0 to 600.0°C –6000 to 6000 –1080.0 to 1080.0°F –10800 to 10800
WRe - –1999.9 to 2400.0°C –19999 to 24000 –4320 to 4320°F –4320 to 4320
