01 Measured value of CH01
(7 characters)
02 Measured value of CH02
(7 characters)
:
24 Measured value of CH24
(7 characters)
(The valid range from 01-24 depends on the
model).
0A Computation channel 0A
(9 characters)
0B Computation channel 0B
(9 characters)
:
1P Computation channel 1P
(9 characters)
(The valid range from 0A-1P depends on
the model).
L01 Message 1 character
(1 character)
L02 Message 2 characters
(2 characters)
:
L16 Message 16 characters
(16 characters)
Space (1 character)
Query VM[ p1]?
Example Message 1 string: Process-1°C
Message 1 printout result:
06/30 10:10 Process-1 134.8°C
Message format 1:
VM 1,M/D H:M L09 01L02
Description • Valid with the header printout (/BT1 option)
when set to use message format (see the UE
command).
• Prints out in the order for parameters specified
by the message format.
• The specified number of characters specified
for standard function messages is used, then
if a subsequent character string has been set,
it is used next. Also, it can only be used once
for the message format.
• The parentheses ( ) indicate the number of
characters used. Set the message format so
that the total number of characters does not
exceed the maximum number allowed.
4.5 Basic Setting Commands
• In order to activate the settings that are
changed using the basic setting commands,
the settings must be saved using the YE or
XE command.
• The settings that are returned in response to a
query in the basic setting mode will contain
the new settings even if they are not saved.
Note
• The settings that are changed using the YS/YB/YA/YN/
YD/YQ/YK command and saved using the XE command
are activated after power-cycling the recorder.
• When the YE command is executed, communication is
dropped.
XA Sets alarm related settings.
Syntax XA p1,p2,p3,p4,p5,p6,p7,p8,p9,p10
<terminator>
p1 Fault diagnosis output ON/OFF (ON, OFF)
p2 Reflash operation ON/OFF (ON, OFF)
p3 Relays that are to operate using AND logic
NONE None (all relays operate using
OR logic)
I01 I01
I01-I02 I01, I02
I01-I03 I01 to I03
I01-I04 I01 to I04
I01-I05 I01 to I05
I01-I06 I01 to I06
I01-I11 I01 to I11 (µR20000)
I01-I12 I01 to I12 (µR20000)
I01-I13 I01 to I13 (µR20000)
I01-I14 I01 to I14 (µR20000)
I01-I15 I01 to I15 (µR20000)
I01-I16 I01 to I16 (µR20000)
I01-I21 I01 to I21 (µR20000)
I01-I22 I01 to I22 (µR20000)
I01-I23 I01 to I23 (µR20000)
I01-I24 I01 to I24 (µR20000)
I01-I25 I01 to I25 (µR20000)
I01-I26 I01 to I26 (µR20000)
I01-I31 I01 to I31 (µR20000)
I01-I32 I01 to I32 (µR20000)
I01-I33 I01 to I33 (µR20000)
I01-I34 I01 to I34 (µR20000)
I01-I35 I01 to I35 (µR20000)
I01-I36 I01 to I36 (µR20000)
p4 Energize/De-energize the relay
ENERGIZE Energize the relay when
an alarm is detected
DE_ENERGIZE De-energize the relay
when an alarm is
detected
