4-29
IM 04P01B01-17E
Commands
4
MC Clears the message printout
buffer.
Syntax MC p1<terminator>
p1 Clear the message printout buffer (0)
Example Clear the message printout buffer.
MC 0
VG Resets the report data of the
periodic printout.
Syntax VG p1<terminator>
p1 Operation type
2 Reset the report data of the periodic
printout.
Example Reset the report data of the periodic printout.
VG 2
Description This setting is valid when the recorder is set to
print the report data using periodic printout.
YC Initializes settings.
Syntax YC p1<terminator>
p1 Initialization type
0 Initialize the Setting mode and Basic
Setting mode settings.
1 Initialize the Setting mode settings.
Example Initialize the Setting mode and Basic Setting
mode settings.
YC 0
UY Stops the record position
adjustment.
Syntax UY p1<terminator>
p1 Fixed to 0.
Query UY?
Example Stop the record position adjustment.
UY 0
Description Returns the execution status of the record
position adjustment in response to a query.
0: Stopped, 1: In progress
4.7 Output Commands
BO Sets the byte output order.
Syntax BO p1<terminator>
p1 Byte order
0 Outputs the data MSB first.
1 Outputs the data LSB first.
Query BO?
Example Output the data MSB first.
BO 0
Description This command applies to the byte order of
numerical data during BINARY output.
CS Sets the checksum (/C3 option).
Syntax CS p1<terminator>
p1 Use/Not use the checksum
0 Not use
1 Use
Query CS?
Example Use the checksum.
CS 1
Description This command can be used only on the RS-
422A/485 communication interface.
IF Sets the status filter.
Syntax IF p1<terminator>
p1 Status filter value
(0.0.0.0 to 255.255.255.255)
Query IF?
Example Set the status filter value to 1.0.4.0.
IF 1.0.4.0
Description For details, see chapter 6.
Note
Initialization of BO/CS/IF Command Settings
• For serial communications
Settings entered using the BO/CS/IF commands
revert to their initial values when the recorder is reset
(when the recorder is power cycled, or the user exits
the basic setting mode with the YE command).
• Byte output order, checksum: 0
• Status filter: 255.255.255.255
If the recorder is reset, you must restore these
settings.
• For Ethernet communications
Settings entered using the BO/IF commands revert to
their initial values when the connection to the recorder
is cut. After reconnecting the recorder, you must
reenter the settings.
4.6 Control Commands/4.7 Output Commands
