3-12
IM 04P01B01-17E
40001 Communication input data of C01
40002 Communication input data of C02
40003 Communication input data of C03
40004 Communication input data of C04
40005 Communication input data of C05
40006 Communication input data of C06
40007 Communication input data of C07
40008 Communication input data of C08
40009 Communication input data of C09
40010 Communication input data of C10
40011 Communication input data of C11
40012 Communication input data of C12
40013 Communication input data of C13
40014 Communication input data of C14
40015 Communication input data of C15
40016 Communication input data of C16
40017 Communication input data of C17
40018 Communication input data of C18
40019 Communication input data of C19
40020 Communication input data of C20
40021 Communication input data of C21
40022 Communication input data of C22
40023 Communication input data of C23
40024 Communication input data of C24
Hold register Data
• Registers corresponding to models with the /M1 computation function option.
• Pen model: C01 to C08, dot model: C01 to C12 (µR10000), C01 to C24 (µR20000)
• The data is a 16-bit signed integer.
• When writing to the register: A 16-bit signed integer only can be input.
• When reading from the register: The communication input data, a floating point, is
converted to a 16-bit signed integer and output.
40301 Communication input data of C01 (lower word)
40302 Communication input data of C01 (upper word)
40303 Communication input data of C02 (lower word)
40304 Communication input data of C02 (upper word)
40305 Communication input data of C03 (lower word)
40306 Communication input data of C03 (upper word)
40307 Communication input data of C04 (lower word)
40308 Communication input data of C04 (upper word)
40309 Communication input data of C05 (lower word)
40310 Communication input data of C05 (upper word)
40311 Communication input data of C06 (lower word)
40312 Communication input data of C06 (upper word)
40313 Communication input data of C07 (lower word)
40314 Communication input data of C07 (upper word)
40315 Communication input data of C08 (lower word)
40316 Communication input data of C08 (upper word)
40317 Communication input data of C09 (lower word)
40318 Communication input data of C09 (upper word)
40319 Communication input data of C10 (lower word)
40320 Communication input data of C10 (upper word)
40321 Communication input data of C11 (lower word)
40322 Communication input data of C11 (upper word)
40323 Communication input data of C12 (lower word)
40324 Communication input data of C12 (upper word)
Hold register Data
(To next page)
3.4
Modbus Slave Protocol Specifications
