3-15
IM 04P01B01-17E
3
Using the RS-422A/485 Communication Interface (/C3 Option)
Explanation
• Address
Select the address from the following range.
01 to 32
• Baud rate
Select the baud rate from the following:
1200, 2400, 4800, 9600, 19200, or 38400
• Data length
Select the data length from below. To output data in BINARY format, be sure to set
the data length to 8 bits.
7 or 8
• Parity (Parity check method)
Select the parity check from the following:
Odd, Even, or None
• Protocol
Select the protocol when using the Modbus slave protocol.
NORMAL: Standard protocol
MODBUS: Modbus slave protocol
• Saving the Settings
To activate the settings made in the Basic Setting mode, the settings must be saved.
3.5 Setting the Serial Interface
To Next Page
