4-14 IM 04P01B01-17E
4.4 Setting Commands
VR Turns ON/OFF the recording on
each channel.
Dot model
Syntax VR p1,p2,p3<terminator>
p1 Channel number
p2 Trend recording ON/OFF (ON, OFF)
p3 Periodic printout ON/OFF (ON, OFF)
Query VR[ p1]?
Example Turn trend recording ON and turn periodic
printout OFF on channel 06.
VR 06,ON,OFF
Description On models with the computation function (/M1
option), computation channels can be specified.
Pen model
Syntax VR p1,p2<terminator>
p1 Channel number
p2 Periodic printout ON/OFF (ON, OFF)
Query VR[ p1]?
Example Turn periodic printing ON on channel 01.
VR 01,ON
Description On models with the computation function (/M1
option), computation channels can be specified.
ST Sets the tag.
Syntax ST p1,p2<terminator>
p1 Channel number
p2 Tag string (up to 7 characters)
Query ST[ p1]?
Example Set the tag of channel 02 to TI-2.
ST 02,TI-2
Description • For the characters that can be used for the
tags, see appendix 1, “ASCII Character
Codes.”
• On models with the computation function (/M1
option), computation channels can be
specified.
SG Sets the message.
Syntax SG p1,p2<terminator>
p1 Message number (1 to 5)
p2 Message string (up to 16 characters)
Query SG[ p1]?
Example Set character string “START” in message
number 1.
SG 1,START
Description For the characters that can be used for the
messages, see appendix 1, “ASCII Character
Codes.”
SE Sets the secondary chart speed
(used by the remote control
function (/R1 option)).
Syntax SE p1<terminator>
p1 Secondary chart speed
See the explanation.
Query SE?
Example Set the chart speed to 50 mm/h.
SE 50
Description Select the chart speed from the list of choices
below.
Pen model
5 to 12000 mm/h (82 levels, see section 4.3)
Dot model
1 to 1500 mm/h (1 mm steps)
SV Sets the moving average
(dot model).
Syntax SV p1,p2<terminator>
p1 Channel number
p2 Number of samples for computing the
moving average (OFF, 2 to 16) [times]
Query SV[ p1]?
Example Set the number of samples for computing the
moving average of channel 02 to 12.
SV 02,12
Description • This setting is available on the dot model.
• This setting is possible when moving average
is enabled (UI command).
SF Sets the input filter (pen model).
Syntax SF p1,p2<terminator>
p1 Channel number
p2 Filter time constant (OFF, 2s, 5s, 10s)
Query SF[ p1]?
Example Set the filter of channel 02 to 2 s.
SF 02,2s
Description This setting is possible when the input filter is
enabled (UJ command).
BD Sets the alarm delay time.
Syntax BD p1,p2<terminator>
p1 Channel number
p2 Alarm delay (1 to 3600) [s]
Query BD[ p1]?
Example Set the alarm delay of channel 01 to 120 s.
BD 01,120
Description • This setting is possible when the alarm delay
function is enabled (UF command).
• On models with the computation function (/M1
option), computation channels can be
specified.
VF Sets the brightness of the display
(VFD) and internal illumination.
Syntax VF p1,p2<terminator>
p1 VFD brightness (1 to 8)
p2 Internal illumination (OFF, 1 to 4)
OFF Turns OFF the internal
illumination.
Query VF?
