2.4 Voltage Source Corresponding to TC Thermoelectromotive Force
2-9
IM CA500-01EN
1
2
3
4
5
6
7
Index
Description
Source Range (TC Type)
You can select from the following 17 TC types.
TC type
(thermocouple)
Source range TC type
(thermocouple)
Source range
K -200.0°C to +1372.0°C B +600.0°C to +1820.0°C
E -250.0°C to +1000.0°C C 0.0°C to +2315.0°C
J -210.0°C to +1200.0°C XK -200.0°C to +800.0°C
T -250.0°C to +400.0°C A 0.0°C to +2500.0°C
N -200.0°C to +1300.0°C D (W3Re/W25Re) 0.0°C to +2315.0°C
L -200.0°C to +900.0°C G (W/W26Re) +100.0°C to +2315.0°C
U -200.0°C to +600.0°C PLATINEL II 0.0°C to +1395.0°C
R -20.0°C to +1767.0°C PR20-40 0.0°C to +1888.0°C
S -20.0°C to +1768.0°C - -
Match the TC type of this instrument to that of the measuring instrument.
Output Terminal
Set whether to use the TC-A terminal (dedicated thermocouple mini plug) or TC-B terminal (banana
terminal).
If you select TC-A terminal, you cannot use an external RJ sensor (sold separately).
When using the TC-B terminal, we recommend that you use the included binding post (99045).
Turning Reference Junction Compensation (RJC) On and Off
When using the TC-B terminal, set whether to perform RJC (ON/OFF).
ON: If an external RJ sensor is connected, the external RJ sensor is used to perform
reference junction compensation.
If an external RJ sensor is not connected, the internal RJ sensor is used to perform
reference junction compensation.
OFF: Reference junction compensation is not performed.
When the TC-A terminal is used, the internal RJ sensor is always used to perform reference
junction compensation.
Note
• The internal RJ sensor measures the temperature of the instrument’s terminal.
• When the temperature inside the instrument is high, wait for the temperature to decrease before use.
• For the external RJ sensor, use the 90080 RJ sensor, sold separately.
Temperature Scale
TC types K, E, J, T, R, S, and B can also handle the IPTS-68 temperature scale..
IPTS-68: The international temperature scale standard of 1968
ITS-90: The international temperature scale standard of 1990
Notes about Sourcing
If you perform a temperature measurement or temperature source using an RJC immediately after
using loop power or simulating 20 mA, the measured value or source value may be affected by the
temperature rise inside the instrument. Wait for the temperature inside instrument to stabilize before
using it.
