2-6
IM CA71-E
g) MEM NO. indicator
Shows a memory number when the memory function is selected.
h) AUTO STEP indicator
Comes on when the auto step function is selected.
i) Divided output function (n/m) indicator
Comes on when the divided output function (n/m) is selected.
The most signicant two digits “18” denote the value of n,
while the least signicant two digits “88” mean the value of m.
j) CAL mode selection indicator
The 0 and FS indicators below this indicator denote zero point and
full scale adjustments, respectively.
k) Battery replacement indicator
Shows the battery level in three steps according to the level of
remaining electricity.
l) RJON indicator
Indicates reference junction compensation is active when
thermoelectromotive force is being sourced.
The thermoelectromotive force output when this indicator is
off represents the 0°C-based output.
2. Names and Functions of Parts
