Page #117 background imageLoading...
Page #117 background image
5-84
IM 710105-17E
:CURSor[:TY]:DEGRee:UNIT
Function Sets or queries the unit of angle cursor
measurement.
Syntax
:CURSor[:TY]:DEGRee:UNIT {<String>}
:CURSor[:TY]:DEGRee:UNIT?
<String> = Up to four characters
Example
:CURSOR:TY:DEGREE:UNIT "DEG"
:CURSOR:TY:DEGREE:UNIT?
-> :CURSOR:TY:DEGREE:UNIT "DEG"
:CURSor[:TY]:DEGRee:V<x>?
Function Queries all angle cursor voltage settings.
Syntax
:CURSor[:TY]:DEGRee:V<x>?
<x> = 1 or 2
:CURSor[:TY]:DEGRee:V<x>:STATe
Function Sets or queries the on/off status of an angle cursor
voltage.
Syntax
:CURSor[:TY]:DEGRee:V<x>:STATe {<Bool
ean>}
:CURSor[:TY]:DEGRee:V<x>:STATe?
<x> = 1 or 2
Example
:CURSOR:TY:DEGREE:V1:STATE ON
:CURSOR:TY:DEGREE:V1:STATE?
-> :CURSOR:TY:DEGREE:V1:STATE 1
:CURSor[:TY]:DEGRee:V<x>:VALue?
Function Queries an angle cursor voltage.
Syntax
:CURSor[:TY]:DEGRee:V<x>:VALue?
<x> = 1 or 2
Example
:CURSOR:TY:DEGREE:V1:VALUE?
-> :CURSOR:TY:DEGREE:V1:VALUE 10.0000
00E−03
:CURSor[:TY]:HORizontal?
Function Queries all ΔVcursorsettings.
Syntax
:CURSor[:TY]:HORizontal?
:CURSor[:TY]:HORizontal:ALL
Function Collectively turns on or off the measured values of
theΔVcursorontheT-Ydisplay.
Syntax
:CURSor:TY:HORizontal:ALL {<Boolean>}
Example
:CURSOR:TY:HORIZONTAL:ALL ON
:CURSor[:TY]:HORizontal:DV?
Function Queries all of the settings for the vertical values
betweentheΔVcursors.
Syntax
:CURSor[:TY]:HORizontal:DV?
:CURSor[:TY]:DEGRee:POSition<x>
Function Sets or queries the position of an angle cursor.
Syntax
:CURSor[:TY]:DEGRee:POSition<x> {<NRf
>}
:CURSor[:TY]:DEGRee:POSition<x>?
<x> = 1 or 2
<NRf>=−5to5(instepsof10divisions/display
record length)
Example
:CURSOR:TY:DEGREE:POSITION1 2
:CURSOR:TY:DEGREE:POSITION1?
-> :CURSOR:TY:DEGREE:POSITION1 2.0000
000
:CURSor[:TY]:DEGRee:REFerence<x>
Function Sets or queries the position of the angle reference
start point (Reference1) or the angle reference
end point (Reference2).
Syntax
:CURSor[:TY]:DEGRee:REFerence
<x> {<NRf>}
:CURSor[:TY]:DEGRee:REFerence<x>?
<x> = 1 or 2
<NRf>=−5to5(instepsof10divisions/display
record length)
Example
:CURSOR:TY:DEGREE:REFERENCE1−1
:CURSOR:TY:DEGREE:REFERENCE1?
-> :CURSOR:TY:DEGREE:REFERENCE1−1.00
00000
:CURSor[:TY]:DEGRee:RVALue
Function Sets or queries the reference angle.
Syntax
:CURSor[:TY]:DEGRee:RVALue {<NRf>}
:CURSor[:TY]:DEGRee:RVALue?
<NRf> = 1 to 720
Example
:CURSOR:TY:DEGREE:RVALUE 180
:CURSOR:TY:DEGREE:RVALUE?
-> :CURSOR:TY:DEGREE:RVALUE 180
:CURSor[:TY]:DEGRee:TRACe
Function Sets or queries the source waveform that you
want to measure using the angle cursors.
Syntax
:CURSor[:TY]:DEGRee:TRACe {<NRf>|ALL|
MATH<x>}
:CURSor[:TY]:DEGRee:TRACe?
<NRf> = 1 to 4 (1 or 2 for 2-channel models)
<x> = 1 or 2 (1 only for 2-channel models)
Example
:CURSOR:TY:DEGREE:TRACE 1
:CURSOR:TY:DEGREE:TRACE?
-> :CURSOR:TY:DEGREE:TRACE 1
