:MEASure:{CHANnel<x>|MATH<x>}{[:AREA
1]|:AREA2}:<Parameter>:COUNt?
Function Queries the statistical processing count of a
waveform parameter in the specified area.
Syntax
:MEASure:{CHANnel<x>|MATH<x>}:{[:ARE
A1]|:AREA2}:<Parameter>:COUNt?
<x> of CHANnel<x> = 1 to 8
<x> of MATH<x> = 1 to 4
<Parameter> =
{AMPLitude|AVERage|
AVGFreq|AVGPeriod|BWIDth|DELay|DT|
DUTYcycle|ENUMber|FALL|FREQuency|
HIGH|LOW|MAXimum|MINimum|
NOVershoot|NWIDth|PERiod|PNUMber|
POVershoot|PTOPeak|PWIDth|RISE|RMS|
SDEViation|TY1Integ|TY2Integ|V1|V2}
Example Below is an example for the average of CH1.
:MEASure:CHANnel1:AREA1:AVERAGE:COU
NT?
-> :MEASure:CHANnel1:AREA1:AVERAGE:C
OUNT 100
:MEASure:{CHANnel<x>|MATH<x>}{[:AREA
1]|:AREA2}:<Parameter>:{MAXimum|MEAN
|MINimum|SDEViation}?
Function Queries a statistical value of a waveform
parameter in the specified area.
Syntax
:MEASure:{CHANnel<x>|MATH<x>}{[:AREA
1]|:AREA2}:<Parameter>:{MAXimum|MEAN
|MINimum|SDEViation}?
<x> of CHANnel<x> = 1 to 8
<x> of MATH<x> = 1 to 4
<Parameter> =
{AMPLitude|AVERage|
AVGFreq|AVGPeriod|BWIDth|DELay|DT|
DUTYcycle|ENUMber|FALL|FREQuency|
HIGH|LOW|MAXimum|MINimum|
NOVershoot|NWIDth|PERiod|PNUMber|
POVershoot|PTOPeak|PWIDth|RISE|RMS|
SDEViation|TY1Integ|TY2Integ|V1|V2}
Example Below is an example for the average of CH1.
:MEASure:CHANnel<x>:AREA1:AVERAGE:MA
XIMUM?
-> :MEASure:CHANnel<x>:AREA1:
AVERAGE:MAXIMUM 10.0000E+03
Description If the statistical value is immeasurable, the
DLM4000 returns “NAN” (not a number).
5.21 MEASure Group
You cannot use commands that relate to logic waveforms on models that are not equipped with logic inputs.
:MEASure?
Function Queries all of the settings for automated
measurement of waveform parameters.
Syntax
:MEASure?
:MEASure:{CHANnel<x>|MATH<x>}?
Function Queries the on/off status of all parameter of a
waveform.
Syntax
:MEASure:{CHANnel<x>|MATH<x>}?
<x> of CHANnel<x> = 1 to 8
<x> of MATH<x> = 1 to 4
:MEASure:{CHANnel<x>|MATH<x>}:{AREA1
|AREA2}?
Function Queries all the parameter ON/OFF settings of the
specified waveform in the specified area.
Syntax
:MEASure:{CHANnel<x>|MATH<x>}:{AREA1
|AREA2}?
<x> of CHANnel<x> = 1 to 8
<x> of MATH<x> = 1 to 4
:MEASure:{CHANnel<x>|MATH<x>}
{[:AREA1]|:AREA2}:ALL
Function Collectively turns on or off all measurement items
of a waveform in the specified area.
Syntax
:MEASure:{CHANnel<x>|MATH<x>}{[:AREA
1]|:AREA2}:ALL {<Boolean>}
<x> of CHANnel<x> = 1 to 8
<x> of MATH<x> = 1 to 4
Example
:MEASURE:CHANNEL1:AREA1:ALL ON
:MEASure:{CHANnel<x>|MATH<x>}
{[:AREA1]|:AREA2}:<Parameter>?
Function Queries the setting of a waveform parameter of a
waveform in the specified area.
Syntax
:MEASure:{CHANnel<x>|MATH<x>}
{[:AREA1]|:AREA2}:<Parameter>?
<x> of CHANnel<x> = 1 to 8
<x> of MATH<x> = 1 to 4
<Parameter> =
{AMPLitude|AVERage|
AVGFreq|AVGPeriod|BWIDth|DELay|DT|
DUTYcycle|ENUMber|FALL|FREQuency|
HIGH|LOW|MAXimum|MINimum|
NOVershoot|NWIDth|PERiod|PNUMber|
POVershoot|PTOPeak|PWIDth|RISE|RMS|
SDEViation|TY1Integ|TY2Integ|V1|V2
}
