5.34 TRIGger Group
The following table indicates how the communication commands for trigger types correspond to the menu items that
appear on the screen.
Trigger Type Communication
Command
Setup Menu
Trigger Menu Trigger Type
Edge trigger
SIMPle
EDGE —
Trigger on the OR of multiple edge triggers
OR
ENHANCED Edge OR
Edge qualified trigger
QUALify
Edge Qualify
State trigger
PATTern
State
Pulse width trigger
PULSe
Pulse Width
State width trigger
WIDTh
State Width
Serial trigger (CAN, CAN FD, LIN, SENT,
PSI5 Airbag, UART, I
2
C, SPI, FlexRay, and
User Define)
CAN*
CAN
CANFD*
CAN FD
LIN*
LIN
SENT*
SENT
PSI5*
PSI5 Airbag
UART*
UART
I2C*
I2C
SPI*
SPI
FLEXray
FlexRay
SPATtern
User Define
TV trigger (NTSC, PAL, SDTV, HDTV, and User
Define)
TV:NTSC
NTSC
TV:PAL
PAL
TV:SDTV
SDTV
TV:HDTV
HDTV
TV:USERdefine
User Define
* CAN, CAN FD, LIN, SENT, PSI5, UART, I2C, SPI, and FLEXray are options. You cannot use commands that
relate to serial busses on models that are not equipped with the appropriate options.
:TRIGger?
Function Queries all trigger settings.
Syntax
:TRIGger?
:TRIGger:ABN?
Function Queries all A->B (N) trigger settings.
Syntax
:TRIGger:ABN?
:TRIGger:ABN:COUNt
Function Sets or queries the number of times condition B
must be met for the A->B (N) trigger.
Syntax
:TRIGger:ABN:COUNt {<NRf>}
:TRIGger:ABN:COUNt?
<NRf> = 1 to 1000000000
Example
:TRIGGER:ABN:COUNT 1
:TRIGGER:ABN:COUNT?
-> :TRIGGER:ABN:COUNT 1
:TRIGger:ACTion?
Function Queries all action-on-trigger settings.
Syntax
:TRIGger:ACTion?
:TRIGger:ACTion:ACQCount
Function Sets or queries the action-on-trigger action.
Syntax
:TRIGger:ACTion:ACQCount {<NRf>|INFi
nite}
:TRIGger:ACTion:ACQCount?
<NRf> = 1 to 1000000
Example
:TRIGGER:ACTION:ACQCOUNT 1
:TRIGGER:ACTION:ACQCOUNT?
-> :TRIGGER:ACTION:ACQCOUNT 1
:TRIGger:ACTion:BUZZer
Function Sets or queries the whether or not the DLM4000
will sound an alarm as an action when trigger
conditions are met (on/off).
Syntax
:TRIGger:ACTion:BUZZer {<Boolean>}
:TRIGger:ACTion:BUZZer?
Example
:TRIGGER:ACTION:BUZZER ON
:TRIGGER:ACTION:BUZZER?
-> :TRIGGER:ACTION:BUZZER 1
:TRIGger:ACTion:HCOPy
Function Sets or queries whether or not the DLM4000 will
print a screen capture as an action when trigger
conditions are met (on/off).
Syntax
:TRIGger:ACTion:HCOPy {<Boolean>}
:TRIGger:ACTion:HCOPy?
Example
:TRIGGER:ACTION:HCOPY ON
:TRIGGER:ACTION:HCOPY?
-> :TRIGGER:ACTION:HCOPY 1
