6-5
IM DLM4038-17EN
Status Reports
1
2
3
4
5
6
App
Index
6.4 Extended Event Register
The extended event register receives information about changes in the condition register, which
indicates the DLM4000’s internal condition. The information is the result of edge detection
performed by the transition filter.
ACS
6
HST
7 5 4 3 2 1 0
PRN TST CAL TRG CUR RUNNGOSCH
8
0
9
MES
1011
NSG
12
0
13
AN
14
0
15
67 5 4 3 2 1 089101112131415
Condition register
:STATus:CONDition?
Transition filter
01415
Extended event register
1
67 5 4 38910111213
2
67 5 4 3 2 189101112131415
16
:STATus:FILTer<x>
{RISE | FALL | BOTH | NEVer}
:STATus:EESR?
FILTer<x> →
The condition register bits are described below.
Bit 0 RUN (Running) This bit is set to 1 when waveform acquisition is in progress.
Bit 1 CUR (Cursor) This bit is set to 1 when cursor measurement is in progress.
Bit 2 TRG (Awaiting trigger) This bit is set to 1 when the DLM4000 is waiting for a trigger.
Bit 3 CAL (Calibration) This bit is set to 1 when calibration is in progress.
Bit 4 TST (Testing) This bit is set to 1 when a self-test is in progress.
Bit 5 PRN (Printing) This bit is set to 1 when the built-in printer is in operation, when
data is being transmitted to a network printer, or when screen
capture data is being saved.
Bit 6 ACS (Accessing) This bit is set to 1 when a drive is being accessed.
Bit 7 MES (Measuring) This bit is set to 1 when automated measurement of waveform
parameters is in progress.
Bit 8 HST (History Search) This bit is set to 1 when a history search is in progress.
Bit 10 NGO (Go/No-go) This bit is set to 1 when a GO/NO-GO search is in progress.
Bit 11 SCH (Search) This bit is set to 1 when a search is in progress.
Bit 12 NSG (N-Single) This bit is set to 1 when consecutive acquisition is in progress
when the trigger mode is set to NSingle.
Bit 14 AN (Analysis) This bit is set to 1 when an analysis is in progress.
The transition filter parameters detect changes in the specified condition register bits (numeric
suffixes 1 to 16) and overwrite the extended event register in the following ways.
RISE The specified extended event register bit is set to 1 when the corresponding condition register
bit changes from 0 to 1.
FALL The specified extended event register bit is set to 1 when the corresponding condition register
bit changes from 1 to 0.
BOTH The specified extended event register bit is set to 1 when the corresponding condition register
bit changes from 0 to 1 or from 1 to 0.
NEVer Always zero.
