3.5 Configuring the DLM4000 GP-IB Settings
This section explains the settings listed below. You must configure these settings when controlling
the DLM4000 remotely through a GP-IB interface.
• Communication interface
• GP-IB address
Opening the Remote Control Menu
Press UTILITY, and then press the Remote Conrol soft key to open the following menu.
Set the communication interface to GP-IB
Set the address (0 to 30)
Note
• Only use the selected communication interface. If you send commands simultaneously from another
communication interface that has not been selected, the DLM4000 will not execute the commands
properly.
• When the controller is communicating with the DLM4000 or with other devices through GP-IB, do not
change the address.
• Each device that is connected by GP-IB has its own unique address in the GP-IB system. This address
is used to distinguish one device from other devices. Therefore, you must assign a unique address to the
DLM4000 when connecting it to a PC or other device.
