5-62
IM DLM4038-17EN
:ANALysis:AHIStogram<x>:MEASure:PARa
meter?
Function Queries all of the measurement settings for
a waveform histogram when the histogram
parameter measurement mode is set to Param.
Syntax
:ANALysis:AHIStogram<x>:MEASure:PARa
meter?
<x> = 1 to 2
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:ALL
Function Collectively turns on or off all of the measurement
items of a waveform histogram.
Syntax
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:ALL {<Boolean>}
<x> = 1 to 2
Example
:ANALYSIS:AHISTOGRAM1:MEASURE:PARAME
TER:ALL ON
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:<Parameter>?
Function Queries all of the settings for the specified
measurement item of a waveform histogram.
Syntax
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:<Parameter>?
<x> = 1 to 2
<Parameter> =
{C1|C2|DC|MAXimum|MEAN|
MEDian|MINimum|PEAK|SD2integ|
SD3integ|SDEViation|SDINteg}
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:<Parameter>:STATe
Function Sets or queries the on/off status of the specified
measurement item of a waveform histogram.
Syntax
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:<Parameter>:STATe {<Boolean>}
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:<Parameter>:STATe?
<x> = 1 to 2
<Parameter> =
{C1|C2|DC|MAXimum|MEAN|
MEDian|MINimum|PEAK|SD2integ|
SD3integ|SDEViation|SDINteg
}
Example Below are examples for the maximum value.
:ANALYSIS:AHISTOGRAM1:MEASURE:PARAME
TER:MAXIMUM:STATE ON
:ANALYSIS:AHISTOGRAM1:MEASURE:PARAME
TER:MAXIMUM:STATE?
-> :ANALYSIS:AHISTOGRAM1:MEASURE:PAR
AMETER:MAXIMUM:STATE 1
5.3 ANALysis Group
You cannot use commands that relate to power supply analysis on models that are not equipped with the optional
power supply analysis feature.
:ANALysis?
Function Queries all of the settings for the analysis feature.
Syntax
:ANALysis?
:ANALysis:AHIStogram<x>?
Function Queries all of the settings for the waveform
histogram feature.
Syntax
:ANALysis:AHIStogram<x>?
<x> = 1 to 2
:ANALysis:AHIStogram<x>:DISPlay
Function Sets or queries the on/off status of a waveform
histogram display.
Syntax
:ANALysis:AHIStogram<x>:DISPlay {<Bo
olean>}
:ANALysis:AHIStogram<x>:DISPlay?
<x> = 1 to 2
Example
:ANALYSIS:AHISTOGRAM1:DISPLAY ON
:ANALYSIS:AHISTOGRAM1:DISPLAY?
-> :ANALYSIS:AHISTOGRAM1:DISPLAY 1
:ANALysis:AHIStogram<x>:HORizontal
Function Sets or queries the horizontal range of a
waveform histogram.
Syntax
:ANALysis:AHIStogram<x>:HORizont
al {<NRf>,<NRf>}
:ANALysis:AHIStogram<x>:HORizontal?
<x> = 1 to 2
<NRf> = −4 to 4 (divisions)
Example
:ANALYSIS:AHISTOGRAM1:HORIZONTAL 0,1
:ANALYSIS:AHISTOGRAM1:HORIZONTAL?
-> :ANALYSIS:AHISTOGRAM1:HORIZONT
AL 1.000E+00,0.000E+00
:ANALysis:AHIStogram<x>:MEASure?
Function Queries all of the settings for waveform histogram
measurement (including the mode on/off status).
Syntax
:ANALysis:AHIStogram<x>:MEASure?
<x> = 1 to 2
:ANALysis:AHIStogram<x>:MEASure:MODE
Function Sets or queries the measurement mode of a
waveform histogram.
Syntax
:ANALysis:AHIStogram<x>:MEASure:MO
DE {OFF|PARameter}
:ANALysis:AHIStogram<x>:MEASure:MO
DE?
<x> = 1 to 2
Example
:ANALYSIS:AHISTOGRAM1:MEASURE:MO
DE OFF
:ANALYSIS:AHISTOGRAM1:MEASURE:MODE?
-> :ANALYSIS:AHISTOGRAM1:MEASURE:MO
DE OFF
