C2-4
IM 34M06H62-02E 2nd Edition : June 2008-00
Data Position Number
Symbol Description Unit Data Range Default Value Attribute Stored
See Also
Loop1 Loop2 Loop3 Loop4
249 449 649 849 3.OH Upper output limit
%
-5.0 to 105.0% if OL OH. OL
is always output if OL OH.
1000 RW
C2.4.2
250 450 650 850 3.OL Lower output limit
0 (or 1000 for
heating/cooling
control)
RW
252 452 652 852 3.HYS
ON/OFF control
hysteresis
Industrial unit
0 to (PRH - PRL) (PRH - PRL) x 0.5% RW
C2.4.1
254 454 654 854 3.GAIN.C Cooling gain % 1 to 999 (1 to 999%) 100 RW
C2.4.3
255 455 655 855 3.HYS.C
Cooling ON/OFF control
hysteresis
Industrial unit
0 to (PRH - PRL) (PRH - PRL) x 0.5% RW
C2.4.4
256 456 656 856 3.DB Dead band Industrial unit
PID control: -10.0 to 10.0% of
(PRH PRL)
ON/OFF control: -50.0 to 50.0% of
(PRH - PRL)
0 RW
C2.4.3
C2.4.4
257 457 657 857 3.POUT Preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW
C7.1
258 458 658 858 3.POUT.C Cooling preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW C7.1
269 469 669 869 4.OH Upper output limit
%
-5.0 to 105.0% if OL OH. OL
is always output if OL OH.
1000 RW
C2.4.2
C6.3
270 470 670 870 4.OL Lower output limit
0 (or 1000 for
heating/cooling
control)
RW
272 472 672 872 4.HYS
ON/OFF control
hysteresis
Industrial unit
0 to (PRH - PRL) (PRH - PRL) x 0.5% RW
C2.4.1
274 474 674 874 4.GAIN.C Cooling gain % 1 to 999 (1 to 999%) 100 RW
C2.4.3
275 475 675 875 4.HYS.C
Cooling ON/OFF control
hysteresis
Industrial unit
0 to (PRH - PRL) (PRH - PRL) x 0.5% RW
C2.4.4
276 476 676 876 4.DB Dead band Industrial unit
PID control: -10.0 to 10.0% of
(PRH PRL)
ON/OFF control: -50.0 to 50.0% of
(PRH - PRL)
0 RW
C2.4.3
C2.4.4
277 477 677 877 4.POUT Preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW
C7.1
278 478 678 878 4.POUT.C Cooling preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW
Changing the Output Type Selection (OUTPUT) parameter, the Output Terminal
Selection (OUTSEL 1-8) parameters, or the Control Type Selection (OT) parameter
automatically initializes related parameters. Therefore, always set up these parameters
before other parameters.
The OUTPUT, OUTSEL 1-8, or OT setting must be enabled to take effect. For details on
how to enable settings, see Section B2.3, "How to Enable Settings."
