C7-10
IM 34M06H62-02E 2nd Edition : June 2008-00
C7.5 Preset Output Function
When the Run/Stop Selection (RUN/STP) is set to “Stop”, the values of the Preset Output
(POUT, POUTC) parameters are output as the control output values.
These values are also output when a burnout or AD converter error is detected provided
the Automatic/Manual/Cascade Selection (A/M/C) parameter is set to “Automatic” or
“Cascade”.
The preset output (POUTC, POUTC) values are unrestricted by the values of the Upper
Output Limit and Lower Output Limit (OH and OL) parameters.
Table C7.9 Parameters Related to Preset Output
Data Position Number
Symbol Description Unit
Data Range
Default
Value
Attribute
Stored
Loop1 Loop2 Loop3 Loop4
217 417 617 817 1.POUT Preset Output % -50 to 1050 (-5.0 to 105.0%) 0 RW
237 437 637 837 2POUT Preset Output % -50 to 1050 (-5.0 to 105.0%) 0 RW
257 457 657 857 3.POUT Preset Output % -50 to 1050 (-5.0 to 105.0%) 0 RW
277 477 677 877 4.POUT Preset Output % -50 to 1050 (-5.0 to 105.0%) 0 RW
218 418 618 818 1.POUT.C Cooling Preset Output % -50 to 1050 (-5.0 to 105.0%) 0 RW
238 438 638 838 2.POUT.C Cooling Preset Output % -50 to 1050 (-5.0 to 105.0%) 0 RW
258 458 658 858 3.POUT.C Cooling Preset Output % -50 to 1050 (-5.0 to 105.0%) 0 RW
278 478 678 878 4.POUT.C Cooling Preset Output % -50 to 1050 (-5.0 to 105.0%) 0 RW
121 321 521 721 RUN/STP Run/Stop Selection None 0: Stop 1: Run 0 RW
