A4-10
IM 34M06H62-02
E
2nd Edition : J
une 2008-00
A4.3.2
T
erminal Wiring Diagram
T
erminal Diagram and Wiring Example for F3CU04-0S
Figure
A4.7 T
erminal
Wiring
Diagram
No wire must be connected to
the terminals marked "NC" in the terminal assignment
diagram or terminal wiring diagram. Otherwi
se, the module will not function normally
. All
output terminals must be wired following inst
ructions given in Section A4.3.1, "Wiring
Precautions."
