B2-6
IM 34M06H62-02E 2nd Edition : June 2008-00
B2.2.3 Setup Control Parameters
Use these parameters to enable various settings, required when controller parameters
and I/O parameters are updated. For details on the procedure, see Section B2.3, “How to
Enable Settings”.
Table B2.5 Setup Control Parameters
Data Position Number
Symbol Description Unit
Data Range
Default
Value
Attribute Stored
See
Also
Loop 1 Loop 2 Loop 3 Loop 4
71 SETUP Setup None
0: Disable setup instruction
operand;
1: Enable setup instruction
operand
0 RW —
B2.3
72 OPE
Setup
instruction
operand
None
1, 2, 4, 8 or 16. For details, see
Table B2.6.
0 RW —
73 STUS
Setup
instruction
response
None
0: No error;
data position number of error
register; or
-32767: Invalid operation (SETUP
= 0)
0 RO —
Table B2.6 Setup Instruction Operand Values (data position number: 72)
Preset
Value
Description Explanation
1 Initialize all parameters Reverts all parameters to their factory settings.
*
1
2
Enable controller
parameters
Enables the controller parameters, which are the most basic setup elements.
The module also initializes I/O parameters and operation parameters based on the controller
parameter values.
4 Enable I/O type settings
Enables the Input Type Selection parameter.
The module also initializes input range settings, PV range settings and operation parameters
based on the input type selection parameter value.
8
Enable input range
settings
Enables the input range settings for measured input as required.
The module initializes PV range settings and operation parameters based on these settings.
16
Enable PV range
settings
Enables the PV range settings, which are required only in Two-input Changeover mode.
The module initializes operation parameters based on these settings.
*1 Input type and power frequency selection defined by the hardware switches have precedence over software settings.
Writing to the Setup Instruction Operand (OPE) register a value that is not listed in Table
B2.6, “Setup Instruction Operand Values (data position number: 72),” has no effect on
module operation. When the setup operation completes, the Setup Instruction Operand
(OPE) register resets to 0.
For details on the procedures for enabling settings, see Section B2.3, “How to Enable
Settings”.
CAUTION
CAUTION
