C2-5
IM 34M06H62-02E 2nd Edition : June 2008-00
C2.1 Control Type Selection
The Control Type Selection function selects the type of control and computation for a
controller.
You can use the Control Type Selection (OT) parameter to select one out of four types of
control and computation function. For details on each type of control and computation
function, see Sections C2.4.1, "ON/OFF Control Output" and C2.4.2, "PID Control
Output."
Table C2.2 Control Type Selection
Data Position Number
Symbol Description Unit Data Range
Default
Value
Attribute
Stored
Loop1 Loop2 Loop3 Loop4
141 341 541 741 OT Control type selection None
0: PID control
1: ON/OFF control
2: Heating/cooling PID control
3: Heating/cooling ON/OFF control
0 RW
The OT setting must be enabled to take effect. For details on how to enable settings, see
Section B2.3, "How to Enable Settings."
C2.2 Output Type Selection
The Output Type Selection (OUTPUT) parameter, available only with F3CU04-1S,
defines what type of output appears at the output terminals.
Set or reset bits of the OUTPUT parameter corresponding to individual terminals to select
either analog (4-20 mA current output) or open collector output for each terminal.
Table C2.3 Output Type Selection
Data
Position
Number
Symbol
Description Relationship between Bit
and Terminal
Data Range
Terminal 15-8
7
6
5
4
3
2
1
0
87 OUTPUT Output
type
selection
1 ——————— 0: Open collector output
(default)
1: Analog output
2 ——————
3 ————— ——
4 ———— ———
5 ——— ————
6 — —————
7 — ——————
8 — ———————
Note: Setting a bit marked by ‘ to 1 or 0 sets up analog output or open collector output for the corresponding terminal.
The OUTPUT setting must be enabled to take effect. For details on how to enable
settings, see Section B2.3, "How to Enable Settings."
