C3.12 External Input
The input value used for monitoring and controlling may be switched to an external input,
which may be, say, processed data from a CPU module.
An external input must fall within the range of -5.0% to 105.0% of (SL to SH).
Use the EXPV/PV parameter to switch between external input and normal input.
An external input may also be used for testing without a thermocouple or sensor
connected.
Table C3.16 External Input Parameters
Data Position Number
Symbol Description Unit Data Range
Default
Value
Attribute
Stored
Loop 1
Loop 2
Loop 3
Loop 4
131 331 531 731 EXPV External input
Industrial
unit
-5.0% to 105.0% of (SL
to SH)
SL RW —
125 325 525 725 EXPV/PV
External/normal
input selection
None
0: Normal input
1: External input
0 RW —
Burnout detection is not performed if the EXPV/PV parameter is set to “1: External Input”.
