YOKOGAWA F3CU04-0S User Manual

C2-14
IM 34M06H62-02E 2nd Edition : June 2008-00
Table C2.13 Parameters Related to Heating/Cooling PID Control (1/2)
Data Position Numbe
r
Symbol Description Unit Data Range Default Value Attribute Stored
Loop 1 Loop 2 Loop 3 Loop 4
134 334 534 734 MOUT Manual output %
OL to OH: for single output
0 to OH: for heating/cooling
output
0 RW —
135 335 535 735 MOUTC
Manual cooling
output
% 0 to OL 0 RW —
206 406 606 806 1.PB Proportional band % 1 to 9999 (0.1 to 999.9%) 50 RW 
207 407 607 807 1.TI Integral time s 0: OFF, 1 to 6000 (1 to 6000 s) 240 RW 
208 408 608 808 1.TD Derivative time s 0: OFF, 1 to 6000 (1 to 6000 s) 60 RW 
209 409 609 809 1.OH
Upper output limit for
PID parameter 1
%
-5.0 to 105.0% if OL ＜ OH.
OL is always output if OL  OH.
1000 RW 
210 410 610 810 1.OL
Lower output limit for
PID parameter 1
0 (or 1000 for
heating/
cooling control)
RW 
211 411 611 811 1.MR Manual reset value % -5.0 to 105.0% 500 RW 
214 414 614 814 1.GAIN.C Cooling gain % 1 to 999 (1 to 999%) 100 RW 
216 416 616 816 1.DB Dead band
Industrial
unit
PID control: -10.0 to 10.0% of
(PRH - PRL)
ON/OFF control: -50.0 to
50.0% of (PRH - PRL)
0 RW 
217 417 617 817 1.POUT Preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW 
218 418 618 818 1.POUT.C
Cooling preset
output
% -50 to 1050 (-5.0 to 105.0%) 0 RW 
226 426 626 826 2.PB Proportional band % 1 to 9999 (0.1 to 999.9%) 50 RW 
227 427 627 827 2.TI Integral time s 0: OFF, 1 to 6000 (1 to 6000 s) 240 RW 
228 428 628 828 2.TD Derivative time s 0: OFF, 1 to 6000 (1 to 6000 s) 60 RW 
229 429 629 829 2.OH Upper output limit
%
-5.0 to 105.0% if OL ＜ OH.
OL is always output if OL  OH.
1000 RW 
230 430 630 830 2.OL Lower output limit
0 (or 1000 for
heating/cooling
control)
RW 
231 431 631 831 2.MR Manual reset value % -5.0 to 105.0% 500 RW 
234 434 634 834 2.GAIN.C Cooling gain % 1 to 999 (1 to 999%) 100 RW 
236 436 636 836 2.DB Dead band
Industrial
unit
PID control: -10.0 to 10.0% of
(PRH - PRL)
ON/OFF control: -50.0 to
50.0% of (PRH - PRL)
0 RW 
237 437 637 837 2POUT Preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW 
238 438 638 838 2.POUT.C
Cooling preset
output
% -50 to 1050 (-5.0 to 105.0%) 0 RW 
246 446 646 846 3.PB Proportional band % 1 to 9999 (0.1 to 999.9%) 50 RW 
247 447 647 847 3.TI Integral time s 0: OFF, 1 to 6000 (1 to 6000 s) 240 RW 
248 448 648 848 3.TD Derivative time s 0: OFF, 1 to 6000 (1 to 6000 s) 60 RW 
249 449 649 849 3.OH Upper output limit
%
-5.0 to 105.0% if OL ＜ OH.
OL is always output if OL  OH.
1000 RW 
250 450 650 850 3.OL Lower output limit
0 (or 1000 for
heating/
cooling control)
RW 
251 451 651 851 3.MR Manual reset value % -5.0 to 105.0% 500 RW 
254 454 654 854 3.GAIN.C Cooling gain % 1 to 999 (1 to 999%) 100 RW 
256 456 656 856 3.DB Dead band
Industrial
unit
PID control: -10.0 to 10.0% of
(PRH - PRL)
ON/OFF control: -50.0 to
50.0% of (PRH - PRL)
0 RW 
257 457 657 857 3.POUT Preset output % -50 to 1050 (-5.0 to 105.0%) 0 RW 
258 458 658 858 3.POUT.C
Cooling preset
output
% -50 to 1050 (-5.0 to 105.0%) 0 RW 
266 466 666 866 4.PB Proportional band % 1 to 9999 (0.1 to 999.9%) 50 RW 
267 467 667 867 4.TI Integral time s 0: OFF, 1 to 6000 (1 to 6000 s) 240 RW 
268 468 668 868 4.TD Derivative time s 0: OFF, 1 to 6000 (1 to 6000 s) 60 RW 
269 469 669 869 4.OH Upper output limit
%
-5.0 to 105.0% if
OL ＜ OH.
OL is always output if OL  OH.
1000 RW 
270 470 670 870 4.OL Lower output limit
0 (or 1000 for
heating/cooling
control)
RW 
271 471 671 871 4.MR Manual reset value % -5.0 to 105.0% 500 RW 
274 474 674 874 4.GAIN.C Cooling gain % 1 to 999 (1 to 999%) 100 RW 
276 476 676 876 4.DB Dead band
Industrial
unit
PID control: -10.0 to 10.0% of
(PRH - PRL)
ON/OFF control: -50.0 to
50.0% of (PRH - PRL)
0 RW 
