6-6
IM MT300-02EN
MT300-D00
Item Specifications
Range 1 kPa
Pressure type Differential pressure
Measurement range (Guaranteed Accuracy Range) 0 kPa to 1 kPa (High input ≥ Low input)
Measurement display range —1.2 kPa to 1.2 kPa
Display resolution 0.00001 kPa
Accuracy (1 year)
(23°C ± 3°C, after
zero calibration)
1
Normal measurement mode
(measurement integration time
4000 ms
2
)
Relative accuracy
3
: ±(0.01% of reading + 0.00025 kPa)
Absolute accuracy: ±(0.02% of reading + 0.00030 kPa)
Display update
interval
4
Normal measurement mode 250 ms
Response time
5
Normal measurement mode 5 s or less
Allowable input 1 Pa abs to 50 kPa gauge
Influence of static pressure Zero point: ±0.00015 kPa / 50 kPa gauge
Influence of temperature ±(0.001% of reading + 0.00005 kPa)/°C
Influence of
positional setup
At 90° forward or backward
inclination
Zero point: ±0.005 kPa
At 5° right or left inclination Zero point: ±0.05 kPa
Weight Approx. 7.2 kg (main unit only, excluding options)
Volume Approx. 12 cm
3
(common to High input and Low input)
Leakage 10
-6
Pa•m
3
/s or less
Measured fluid Gas and liquid (nonflammable, nonexplosive, nontoxic, noncorrosive fluid)
Substances and mixtures defined in Directive 2014/68/EC Article 13(1)a
are excluded.
Measured fluid temperature 10°C to 35°C
Fluid kinematic viscosity 5×10
–6
m
2
/s or less
1 Zero-point calibration condition: Under atmospheric pressure
2 When the measurement integration time is 2500 ms or less, add ±0.00070 kPa to the accuracy.
3 A value relative to the YOKOGAWA working standard
4 The data output interval through communication is the same as the display update interval.
5 Conditions of response time measurement:
• The time from when the change starts to when the value settles within ±1% of the convergence value.
• From the full scale value, open the input to the atmosphere (with the input section under no load).
• Measure using D/A output.
• When the measurement integration time is 4000 ms
6.1 Pressure Measurement Specifications
