YOKOGAWA MT300 Getting Started Guide

6-1
IM MT300-02EN
Specifications
1
2
3
4
5
6
App
Index
6.1 Pressure Measurement Specifications
MT300-G01
Item Specifications
Range 10 kPa
Pressure type Gauge pressure
Measurement range (Guaranteed Accuracy Range) Positive pressure: 0 kPa to 10 kPa, negative pressure: –10 kPa to 0 kPa
Measurement display range —12 kPa to 12 kPa
Display resolution 0.0001 kPa, 0.00001 kPa on models with the /R1 option
Accuracy (1 year)
(23°C ± 3°C, after
zero calibration)
1
Normal measurement mode
(measurement integration time
1500 ms or more
2
)
Positive pressure
Relative accuracy
3
: ±0.01% of full scale
Absolute accuracy: ±(0.015% of reading + 0.0015 kPa)
Negative pressure
Relative accuracy
3
: ±(0.1% of reading + 0.0050 kPa)
Absolute accuracy: ±(0.2% of reading + 0.0100 kPa)
Medium-speed measurement
mode
4
Add ±0.002 kPa to the accuracy for normal measurement mode
High-speed measurement mode
4
Add ±0.006 kPa to the accuracy for normal measurement mode
Display update
interval
5
Normal measurement mode 250 ms
Medium-speed measurement
mode
4
100 ms
High-speed measurement mode
4
100 ms
Response time
6
Normal measurement mode 2.5 s or less
Medium-speed measurement
mode
4
200 ms or less
High-speed measurement mode
4
100 ms or less
Allowable input 2.7 kPa abs to 50 kPa gauge
Influence of temperature Positive pressure: ±(0.001% of reading + 0.00015 kPa)/°C
Negative pressure: ±(0.001% of reading + 0.00015 kPa)/°C
Influence of
positional setup
At 90° forward or backward
inclination
Zero point: ±0.01 kPa
At 30° right or left inclination Zero point: ±0.25 kPa
Weight Approx. 7.0 kg (main unit only, excluding options)
Volume Approx. 12 cm
3
Leakage 10
-6
Pa•m
3
/s or less
Measured fluid Gas and liquid (nonflammable, nonexplosive, nontoxic, noncorrosive fluid)
Substances and mixtures defined in Directive 2014/68/EC Article 13(1)a
are excluded.
Measured fluid temperature 5°C to 50°C
Fluid kinematic viscosity 5×10
–6
m
2
/s or less
1 Zero-point calibration condition: Under atmospheric pressure
2 When the measurement integration time is 250 ms, add ±0.0007 kPa to the accuracy.
3 A value relative to the YOKOGAWA working standard
4 On models with the /F1 option, the measurement mode can be switched between normal, medium speed, and high speed.
5 The data output interval through communication is the same as the display update interval.
6 Conditions of response time measurement:
• The time from when the change starts to when the value settles within ±1% of the convergence value.
• From the full scale value, open the input to the atmosphere (with the input section under no load).
• Measure using D/A output.
• When the measurement integration time is 1500 ms
Chapter 6 Specifications
