YOKOGAWA MT300 Getting Started Guide

6-10
IM MT300-02EN
6.2 Voltage Input (V)/Current Input (A) and 24 VDC
output Specifications (/DM option)
Item Specifications
Voltage Input (V)/
Current Input (A)
Measurement
range
DCV: 5 VDC range, DCA: 20 mADC range
Guaranteed
Accuracy Range
DCV: 0 V to ±5.25 V, DCA: 0 mA to ±21 mA
Measurement
display range
DCV: 0 V to ±6 V, DCA: 0 mA to ±24 mA
Display
resolution
DCV: 0.0001 V, DCA: 0.001 mA
Accuracy (1 year)
23°C±3°C
DCV: ±(0.015% of reading + 0.5 mV)
DCA: ±(0.015% of reading + 3 µA)
Measurement
time
Approx. 300 ms (when AVERAGE OFF)
Response time Approx. 500 ms (when AVERAGE OFF)
Allowable input DCV: ±30 V, DCA: ±100 mA
Input resistance DCV: Approx. 1 MΩ, DCA: Approx. 10 Ω
Influence of
temperature
±(0.01% of reading + 2digits)/10°C
CMRR 100 dB or more (50 Hz/60 Hz, Rs=1 kΩ)
NMRR 60 dB or more (50 Hz/60 Hz)
Terminal Plug-in terminal (Φ4mm banana jack (female type))
24 VDC output Supply voltage,
current
Communication resistance is off: 24 V±1 VDC, 24 mA
Communication resistance is on: 24 V±6 VDC, 20 mA
Maximum output
current
30 mA (current limit approx. 40 mA)
Load capacitance 0.1 µF or less
Communication
resistance
250 Ω ON/OFF
Terminal Plug-in terminal (Φ4mm banana jack (female type))
Rated voltage to ground (between all signal input terminals and ground): 42 Vpeak
