YOKOGAWA MT300 Getting Started Guide

6-11
IM MT300-02EN
Specifications
1
2
3
4
5
6
App
Index
6.3 D/A output and comparator output Specifications
(/DA option)
Item Specifications
D/A output Source range 2 VDC range, 5 VDC range
Guaranteed
Accuracy Range
2 VDC range: 0 V to ±2 V, 5 VDC range: 0 V to ±5 V
Output
resolution
16 bit
Output range Approx. ±120% of the range
Output accuracy
(1 year)
(23°C±3°C,
when pressure
is stable)
When dynamic mode is off: Add ±0.05% of full scale to the pressure
accuracy
Dynamic mode on
1
: ±0.5% of full scale
±0.7% of full scale (when -G01 is selected)
Output update
interval
Dynamic mode off: Approx. 2 ms (normal measurement mode)
Approx. 0.25 ms (medium-speed/high-speed
measurement mode
1
)
Dynamic mode on
1
: Approx. 0.25 ms
Response time
2
Dynamic mode off: Conforms to the pressure measurement specifications
Dynamic mode on
1
: Conforms to the high-speed mode of pressure
measurement specifications
Output
resistance
0.1 Ω or less
Influence of
temperature
±(0.005% of full scale)/°C
Load resistor 10 kΩ or more
Load
capacitance
0.1 µF or less
Terminal BNC terminal
Comparator output Output signal HI/IN/LO, BUSY
Output range —0.3 V to 5.5 V
Output level HIGH: 3.5 V or more, LOW: 0.45 V or less
Terminal Detachable terminal block
1 All models with the /F1 option, the dynamic mode can be turned on and off, and the measurement
mode can be switched between normal, mid-speed, and high-speed.
2 The time from when the change starts to when the value settles within ±1% of the convergence
value.
Rated voltage to ground (between the D/A output terminal and ground): 42 Vpeak
The comparator output GND is grounded.
