6-13
IM MT300-02EN
Specifications
6
6.5 Communication Specifications
Item Specifications
USB PC Connector type USB type B (receptacle)
Electrical and
mechanical
USB Rev. 2.0 compliant
Supported transfer
modes
HS (High Speed) mode (480 Mbps)
FS (Full Speed) mode (12 Mbps)
Supported protocols USB-FUNCTION interface
USBTMC-USB488 (USB Test and Measurement Class Ver.1.0)
Virtual COM port
CDC (Communication Device Class)
Storage
Mass storage devices that comply with USB Mass Storage
Class Ver. 1.1
ETHERNET Connector type RJ-45 connector
Electrical and
mechanical
IEEE 802.3 compliant
Transmission system 100 BASE-TX/10 BASE-T
Transfer rate 100 Mbps max.
Protocol TCP/IP
Supported services DHCP/VXI-11
GP-IB Electrical and
mechanical
Complies with IEEE St’d 488-1978
Functional specifications SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, and C0
Protocol Complies with IEEE St’d 488.2-1992
Address 0 to 30
To Next Page
