IM 253401-01E
1-4
Remote Control Functions (option)
External Input
This instrument can be controlled using the following TTL-level, low pulse, logic signals.
EXT HOLD (when options /DA4, /DA12, /CMP are installed)
Holds updating of the displayed values or releases the hold status.
EXT TRIG (when options /DA4, /DA12, /CMP are installed)
Updates the displayed values in hold mode.
EXT START (when options /DA4, /DA12 are installed)
Starts integration.
EXT STOP (when options /DA4, /DA12 are installed)
Stops integration.
EXT RESET (when options /DA4, /DA12 are installed)
Resets the integration results.
External Output
This instrument can output the following TTL-level, low pulse, logic signals.
EXT BUSY (when options /DA4, /DA12 are installed)
Outputs continuously from integration start through integration stop.
Communication Functions
Either a GP-IB or RS-232-C interface is provided as standard according to the custormer’s
preference. Measured/computed data of up to 14 channels can be output. It is also possible to
control this instrument from the personal computer.
Output Function to an External Plotter / Printer
Measured/computed data can be printed on an external plotter or printer using the GP-IB or RS-
232-C interface.
Other Useful Functions
Backup Function of Set-up Parameters
This instrument backs up the set-up parameters (including computed values) in case power is
cut off accidentally as a result of a power failure or for any other reason.
Initializing Set-up Parameters
This function enables you to reset the set-up parameters to initial (factory) settings.
1.2 Functions
To Next Page
