YOKOGAWA WT110 User Manual

IM 253401-01E
App2-22
Appendix 2.3 Commands
MEASure?
Function Queries all the settings related to measurement/
computation data.
Syntax MEASure?
Example Example of WT130 three-phase four-wire model
(ROM version 2.01)
MEASURE? → :MEASURE:NORMAL:ITEM:V:ELEMENT1 1;
ELEMENT2 1;ELEMENT3 1;SIGMA 1;:MEASURE:
NORMAL:ITEM:A:ELEMENT1 1;ELEMENT2 1;
ELEMENT3 1;SIGMA 1;:MEASURE:NORMAL:ITEM:W:
ELEMENT1 1;ELEMENT2 1;ELEMENT3 1;SIGMA 1;:
MEASURE:NORMAL:ITEM:VA:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:VAR:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:PF:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:DEGREE:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:VHZ:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:AHZ:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:WH:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:WHP:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:WHM:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:AH:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:AHP:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:AHM:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:VPK:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:APK:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;:
MEASURE:NORMAL:ITEM:TIME 0;MATH 0;:MEASURE:
HARMONICS:ITEM:SYNCHRONIZE 1;VTHD 1;V 1;
VCON 1;ATHD 0;A 0;ACON 0;PF 0;W 0;WCON 0;
VDEG 0;ADEG 0
MEASure:HARMonics?
Function Queries all settings related to harmonic analysis data.
Syntax MEASure:HARMonics?
Example MEASURE:HARMONICS? → :MEASURE:HARMONICS:ITEM:
SYNCHRONIZE 1;VTHD 1;V 1;VCON 1;ATHD 0;A 0;
ACON 0;PF 0;W 0;WCON 0;VDEG 0;ADEG 0
MEASure:HARMonics:ITEM?
Function Queries all settings related to the communication
output items of harmonic analysis data.
Syntax MEASure:HARMonics:ITEM?
Example MEASURE:HARMONICS:ITEM? → (Same result as for
MEASure:HARMonics?)
MEASure:HARMonics:ITEM:PRESet
Function Sets the ON/OFF pattern for all communication
outputs of the harmonic analysis function.
Syntax MEASure:HARMonics:ITEM:PRESet {VPATtern|
APATtern|WPATtern|DPATtern|ALL|CLEar}
Example MEASURE:HARMONICS:ITEM:PRESET VPATTERN
Description The following six patterns can be selected.
VPATtern:SYNChronize/VTHD/V/VCON → ON,
others→ OFF
APATtern:SYNChronize/ATHD/A/ACON → ON,
others→ OFF
WPATtern:SYNChronize/PF/W/WCON → ON,
others→ OFF
DPATtern:SYNChronize/VDEG/ADEG → ON,
others→ OFF
ALL : all items→ ON
CLEar : all items→ OFF
MEASure:HARMonics:ITEM:{SYNChronize|<harmonic
analysis function>}
Function Sets the communication output item of harmonic
analysis ON/OFF, queries the current setting.
Syntax MEASure:HARMonics:ITEM:{SYNChronize|
<harmonic analysis function>} {<Boolean>}
MEASure:HARMonics:ITEM:{SYNChronize|
<harmonic analysis function>}?
<harmonic analysis function>={VTHD|V|VCON|
ATHD|A|ACON|PF|W|WCON|VDEG|ADEG}
SYNChronize=PLL source
Example MEASURE:HARMONICS:ITEM:VTHD ON
MEASURE:HARMONICS:ITEM:VTHD? → :MEASURE:
HARMONICS:ITEM:VTHD 1
Description The selection SYNChronize is for outputting the
frequency of the PLL source.
You can query the PLL source input by the command
HARMonics:SYNChronize?
MEASure:HARMonics:VALue?
Function Queries harmonic analysis data set by commands
other than” MEASure:HARMonics:ITEM ”.
Syntax MEASure:HARMonics:VALue?
Example MEASURE:HARMONICS:VALUE? → 60.00E+00,
12.01E+00,49.98E+00,49.62E+00,0.03E+00,
5.50E+00,.....
Description • The renewal of harmonic analysis data output here
occurs when bit0 (UPD) of the condition register
(refer to page App2-38) changes from high to low.
For more details, refer to 2.2.6.
• For the output format of harmonic analysis data,
refer to page App2-25.
MEASure:NORMal?
Function Queries all settings related to normal measured/
computed data.
Syntax MEASure:NORMal?
Example Example of WT130 three-phase four-wire model
(ROM version 2.01)
MEASURE:NORMAL? → :MEASURE:NORMAL:ITEM:V:
ELEMENT1 1;ELEMENT2 1;ELEMENT3 1;SIGMA 1;
:MEASURE:NORMAL:ITEM:A:ELEMENT1 1;ELEMENT2 1;
ELEMENT3 1;SIGMA 1;:MEASURE:NORMAL:ITEM:W:
ELEMENT1 1;ELEMENT2 1;ELEMENT3 1;SIGMA 1;
:MEASURE:NORMAL:ITEM:VA:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:VAR:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:PF:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;
:MEASURE:NORMAL:ITEM:DEGREE:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:VHZ:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:AHZ:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;
:MEASURE:NORMAL:ITEM:WH:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:WHP:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:WHM:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;
:MEASURE:NORMAL:ITEM:AH:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:AHP:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:AHM:
ELEMENT1 0;ELEMENT2 0;ELEMENT3 0;SIGMA 0;
:MEASURE:NORMAL:ITEM:VPK:ELEMENT1 0;
ELEMENT2 0;ELEMENT3 0;SIGMA 0;:MEASURE:
NORMAL:ITEM:APK:ELEMENT1 0;ELEMENT2 0;
ELEMENT3 0;SIGMA 0;:MEASURE:NORMAL:ITEM:
TIME 0;MATH 0
