YOKOGAWA WT110 User Manual

IM 253401-01E
10-6
10.3 D/A Output (optional)
Relation between the output item and the D/A output voltage
D/A output
Displayed
value [Hz]
4
0.2V
0.5V
2.5V
5.0V
10
100
1k
10k
50k
Approx. 7.5V
• Frequency
• Integrated value
D/A output
Time
0
In case of rated
value input
In case of 140% of
rated value input
t
o
:rated integration time
Approx. 7.0V
5.0V
• Other items
Displayed
value[%]
D/A output
Approx. 7.5V
Approx. 7.0V
5.0V
–5.0V
Approx. –7.0V
Approx. –7.5V
Displayed value
140%
100%
0%
–100%
–140%
Output
Approx. 7.0V
5.0V
0V
–5.0V
Approx. –7.0V
However, for PF and deg, points in
the range from +5 to +7 V and from
–5 to –7 V are not output.
If there is an error, the output will
be about ±7.5 V. If the MATH setting
is set to efficiency, the output will be
+5 V for 100%.
For Vp and Ap, the output will be
±5 V when the value is three times
the range rating. In addition, output
will not be ±7.5 V when Vp and Ap
are over the range.
–140
–100
100 140
t
o
