York EX Series - FIGURE 51 - Location of Manual Valve in Purging System 120-300 EX(H;S)

JOHNSON CONTROLS
131
SECTION 7 – MAINTENANCE
FORM 155.32-ICOM1.EN.GB
ISSUE DATE: 10/13/2017
7
A
B
C
D
E
F
H
G
LD20189
180EX(S/H)NG - 300EX(S/H)NG
FIGURE 51 - LOCATION OF MANUAL VALVE IN PURGING SYSTEM 120-300EX(H/S)
A Purge valve from purge tank (V10)
B Purge valve from absorber (V13)
C Purge valve from absorber (V11)
D Purge Main Valve (V14)
E Purge valve from absorber (V16)
F C/H Changeover Valve VL (Option)
G Refrigerant Blow Valve (V8)
H Refrigerant Pump
Gas Duct Side View Evaporator Side View
120-300EX(H/S)
